3BHE039724R0C3D PPD513AOC-100440 Excitation Controller
Product Details Introduction
Summary of Instruction Manual for 3BHE039724R0C3D PPD513AOC-100440 Excitation Controller
1、 Product Overview
3BHE039724R0C3D PPD513AOC-100440 excitation controller is a high-performance control equipment launched by ABB, designed specifically for generator excitation control in power systems. This controller has powerful control functions and flexible programming capabilities, which can meet the excitation control requirements under various complex working conditions.
2、 Technical specifications
Model: 3BHE039724R0C3D PPD513AOC-100440
Rated voltage: 12 kV
Rated current: 630 A
Operation mode: Electric operation
Protection functions: including overcurrent, short circuit, overvoltage, undervoltage, etc
Measurement function: capable of measuring current, voltage, power, etc
3、 Functional characteristics
High precision control: Advanced control algorithms and high-speed processors are used to achieve high-precision control of generator excitation current.
Multiple protection functions: Built in multiple protection functions to ensure the safe operation of the generator under various working conditions.
Flexible programming ability: Supports multiple programming languages, making it convenient for users to program and configure according to their actual needs.
Rich communication interfaces: Provides multiple communication interfaces, supporting data exchange and communication with other devices and systems.
High reliability: Adopting ABB's mature technology and strict quality control system to ensure product stability and reliability.
4、 Application field
This excitation controller is widely used in power plants, substations, transmission lines, and other equipment in the power system, for excitation control, protection, and monitoring of generators.
5、 Installation and Maintenance
Installation: Please follow the installation steps and precautions in the product manual to ensure that the controller is installed and connected correctly.
Maintenance: Regularly check the operation status of the controller, keep it clean and dry. If there is any malfunction or abnormal situation, please contact professional maintenance personnel in a timely manner for handling.
6、 Safety instructions
Preparation before operation: Please carefully read the product manual before operation to understand the usage method and safety precautions of the product.
Operation precautions: When the power is turned on, please do not perform unnecessary disassembly or maintenance operations on the controller to avoid electric shock or damage to the equipment.
Maintenance and upkeep: When conducting maintenance and upkeep, please ensure that the power is turned off and take appropriate safety measures.
Product image
