Product Details Introduction

ProSoft PLX35-NB2 Ethernet Communication Module Manual

1、 Product Overview

ProSoft PLX35-NB2 is a powerful Ethernet communication module designed specifically for industrial automation and control systems. This module supports multiple Ethernet communication protocols, such as EtherNet/IP, Modbus TCP, Profinet, etc., providing high-speed data transmission and real-time data exchange capabilities. Through PLX35-NB2, users can easily expand the I/O points of PLC or other controllers to meet the communication needs of complex systems.

2、 Main functions

Ethernet communication: Supports Ethernet communication protocols such as EtherNet/IP, Modbus TCP, Profinet, etc., ensuring efficient data transmission and real-time exchange.

I/O extension: allows users to expand the I/O points of PLC or other controllers through Ethernet connection, supporting discrete input/output, analog input/output, etc.

Configuration and Programming: Provides easy-to-use configuration and programming tools such as RSLogix 5000, Studio 5000, etc., supporting graphical interfaces for module configuration and programming.

Network diagnosis: It has network status monitoring and diagnostic functions, supports SNMP protocol or other network management tools, and helps users quickly identify and solve network problems.

Data recording and reporting: Allow users to record data and generate reports for trend analysis, fault diagnosis, and performance optimization.

3、 Features and advantages

High speed transmission: Supports high-speed data transmission and meets high real-time requirements in application scenarios.

Easy to integrate: Provides integration capabilities with various PLC, HMI, SCADA systems, and other industrial equipment, supporting multiple communication protocols and interfaces.

Remote access: achieved through the Belden Horizo n platform, supporting monitoring and management of automated devices anytime, anywhere.

Security: Supports encrypted communication and data integrity checks to ensure the security of data during transmission. Provide access control and user permission management functions to restrict unauthorized access to modules.

4、 Specification parameters

Supported PLC types: PLC2, PLC5, SLC, CLX, CMPLX, MICROLX, etc.

Supported message types: PCCC and CIP.

Number of server connections: Up to 5 connections for 3 types of servers.

Number of client connections: Among the 3 types of client connections, 2 are connected and 1 is not.

Number of I/O connections: The number of Class 1 I/O connections reaches 2, and the size of the I/O connections is 248/248.

RPI time: 5 milliseconds per connection.

5、 Physical characteristics and environmental adaptability

Physical characteristics: including specific information such as module size, weight, connector type, indicator lights, etc.

Power and Power Supply: Describe the power requirements and power supply methods of the module (such as DC power supply, PoE, etc.), and provide detailed information about power connection and protection.

Environmental adaptability: Provide environmental adaptability information such as the operating temperature range, humidity range, dust and waterproof level of the module, and describe the module's tolerance to vibration, impact, and electromagnetic interference.

6、 Installation and Maintenance

Installation: Install according to the installation steps and precautions in the product manual to ensure that the module is correctly connected and fixed.

Maintenance: Regularly check the operating status and performance indicators of the module. If there are any abnormalities, please contact professional maintenance personnel in a timely manner for handling. Meanwhile, keep the module clean and dry to avoid damage caused by dust and moisture.

7、 Safety instructions

Please read the product manual carefully before operation to understand the usage method and safety precautions of the product.

Avoid unnecessary disassembly or maintenance operations on the module when the power is turned on to avoid electric shock or damage to the equipment.

Please ensure that the module is installed in a compliant working environment to avoid adverse factors such as high or low temperature and humidity from affecting it.
