DS200DCFBG1BKC driver module
Product Details Introduction
DS200DCFBG1BKC Driver Module Manual
1、 Product Overview
DS200DCFBG1BKC is a high-performance driver module produced by General Electric (GE) and belongs to the Mark V series power board. This module is designed specifically for industrial automation applications, providing precise motion control and signal processing.
2、 Main functions and characteristics
High performance and wide speed range:
Adopting advanced electronic technology and algorithms, providing high-precision and highly responsive motion control.
Supports a wide range of speed regulation, achieving precise control from low to high speeds.
Flexible interface:
Supports multiple communication protocols, such as Profinet, EtherCAT, etc., facilitating integration with various control systems.
Comprehensive protection functions:
Built in protection functions such as overcurrent, overvoltage, and undervoltage ensure equipment and personal safety.
Easy to use and maintain:
Provide a simple and easy to understand user interface and operation buttons, making it convenient for users to set up and control.
Supports hot swapping function, making it easy to replace and upgrade.
High reliability:
Using high-quality materials and manufacturing processes to ensure long-term stable operation in harsh environments.
3、 Technical parameters
Model: DS200DCFBG1BKC
Series: Mark V Series Power Board
Working voltage: 140V
Output frequency: 0 to 500kHz (depending on input voltage)
Rated source input: can safely measure voltage between 38 and 115VAC
LD instruction processor: hard PLC
I/O points: 480
Structural form: modular
Installation method: Control room installation
4、 Circuit composition
DS200DCFBG1BKC consists of five independent circuits, including:
Control level power circuit
drive circuit
Motor magnetic field power supply circuit
AC monitoring circuit
DC monitoring circuit
5、 Configuration and monitoring
Configuration: The circuit board provides 12 jumpers and 7 DIP switches, which can be configured according to user requirements.
Monitoring and diagnosis: Presenting diagnostic information on fuses to users through two LED indicator lights and a neon indicator light.
6、 Compatibility
In GE's drive system, DS200DCFBG1BKC is compatible with DC2000, AC2000, FC2000, CB2000, and ME2000 series drives.
7、 Installation and Maintenance
Please refer to the equipment's data sheet and manual for complete guidance on wiring and installing circuit boards. Please follow the installation parameters to protect the entire device from any accidental damage.
Product image
