Emerson 1C31219G01 Input/Output Module

Emerson 1C31219G01 Input/Output Module

Product Details Introduction

Emerson 1C31219G01 Input/Output Module Manual

1、 Product Overview

The Emerson 1C31219G01 I/O module is a critical industrial automation component produced by Emerson Automation Solutions (formerly known as Emerson Process Management). This module is commonly used in industrial automation and control systems to achieve the conversion between digital signals and relay output signals, in order to control various equipment and systems.

2、 Main functions

Signal conversion: The module converts the received digital signal into a relay output signal, thereby achieving precise control of the target equipment or system.

Logic control: Based on preset programs or external input signals, the module can control the opening and closing status of relays to meet complex control requirements.

System integration: The module supports multiple communication protocols and interfaces, facilitating integration with other control systems, PLCs, HMI, and other devices.

3、 Technical specifications

Data electrical interface:

A 9-pin Sub-D socket connector with pin definitions that comply with the protocol specifications of Profibus DP.

Supports the Profibus DP bus standard.

Communication speed: Supports multiple speed settings, including 9.6kBit/s to 12MBit/s.

Signal delay (electrical port): ≤ 11Bit.

Equipped with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions.

Fiber optic interface:

Fiber wavelength: Supports both multimode and single-mode fibers.

Transmission fiber: including multimode 50/125 um, 62.5/125 um, etc.

Transmission distance: Multi mode up to 2Km, single mode up to 20Km.

Fiber optic interface types: SC, FC, ST optional, standard SC optical interface.

4、 Features and advantages

High reliability: The module design considers multiple mechanisms for protection, ensuring long-term stable operation in various industrial environments.

Flexibility: Logically independent dual bus electrical interface, supporting backup of electrical interfaces or single device access to dual redundant bus systems, providing multiple network topology choices.

Self healing protection function: Adopting dual optical ports to achieve dual fiber ring network redundancy function, when a fiber optic failure occurs in a certain area, the system can quickly rebuild the network link, ensuring normal communication.

Usability: Plug and play design, no configuration required, simplifies user installation and debugging process.

5、 Installation and Maintenance

Please follow the installation steps and precautions in the product manual to ensure that the module is properly connected and secured. Regularly check the operating status and performance indicators of the module. If there are any abnormalities, please contact professional maintenance personnel for timely handling.

6、 Safety instructions

Please read the product manual carefully before operation to understand the usage method and safety precautions of the product. Avoid unnecessary disassembly or maintenance operations on the module when the power is turned on to avoid electric shock or damage to the equipment.

7、 Application scope

The Emerson 1C31219G01 I/O module is suitable for application scenarios that require precise control and reliable operation, such as industrial automation production lines, building control systems, power monitoring systems, etc.

Product image
