PPC380AE01 HIEE300885R1 Analog Input Module

Product Details Introduction

PPC380AE01 HIEE300885R1 Analog Input Module Manual

1、 Product Overview

The PPC380AE01 HIEE300885R1 analog input module is a high-performance module produced by ABB, designed specifically for industrial automation systems. This module is used to monitor and collect analog signals such as temperature, pressure, flow rate, etc., and convert them into digital signals for use in control systems or data acquisition systems.

2、 Technical specifications

Module type: Analog input module

Signal type: supports multiple types of analog signals, such as temperature, pressure, flow rate, etc

Range: Not specifically mentioned, but based on the characteristics of similar modules, it may cover a wide range from low range to high range

Accuracy: ≤ 0.5% FS (within 0.5% of full scale)

Sensitivity: 2 ± 1mV/V

Bridge voltage supply: 5-15VDC (recommended 10VDC)

Overload allowed: 150% FS

Input impedance: 700 ± 15 Ω

Output impedance: 650 ± 15 Ω

Creep: ± 0.05% FS/30min

Insulation resistance: ≥ 5000M Ω

Working temperature range: -20 ℃~+70 ℃

Material: 2Cr13 (martensitic stainless steel)

3、 Functional characteristics

Multi channel support: Modules typically have multiple independent analog input channels, each of which can process an analog signal.

Signal conversion: Convert analog signals into digital signals for easy use in control systems or data acquisition systems.

Amplification and filtering: The module may provide amplification and filtering functions for the input signal to enhance signal quality and stability.

Calibration capability: The module may have calibration capabilities to ensure the accuracy and precision of the input signal.

Durable and sturdy: The all stainless steel structure and sturdy and durable design use well-known domestic brand strain gauges and imported glue to ensure long-term functional stability.

Miniature design: Small in size, suitable for use in limited space situations.

4、 Installation and Connection

Wiring method:

Input: Exc+(red), Exc - (black)

Output: Sig+(green), Sig - (white)

C-R+(other wiring points not mentioned)

5、 Precautions

Please ensure that the module is used within the specified power and signal range.

Before performing any maintenance or repair operations, please ensure that the module is completely powered off.

Please follow the relevant safety operating procedures and guidelines to ensure the stable operation of the module.
