GDB021BE GDB021BE01 HIEE300766R0001 Synchronizer module
Product Details Introduction
GDB021BE GDB021BE01 HIEE300766R0001 Synchronizer Module Manual
1、 Product Overview
GDB021BE GDB021BE01 HIEE300766R0001 is a synchronizer module specifically designed for synchronous control of generators in power systems. This product is produced by ABB and aims to ensure synchronous operation of the generator with other generators or grids in the power system, in order to achieve safe and reliable power transmission and generator grid connection.
2、 Technical specifications
Function:
Generator synchronization control: used to control the matching of voltage, frequency, and phase parameters between the generator and the power system.
Automatic synchronization function: monitors the voltage and frequency in the power system, synchronizes with other generators, and automatically performs grid connection operation when synchronization conditions are met.
Synchronous protection function: equipped with various synchronous protection functions to protect the generator and power system from potential faults and damage.
Interface and Communication:
Provide a user-friendly interface and monitoring functions for easy operation and monitoring of synchronization processes.
Real time parameters of the generator and power system can be displayed, providing operation instructions and alarm information.
Programmability and flexibility:
With programmable functions and flexible configuration options, users can set parameters and program logic according to specific needs.
Electrical parameters:
The specific parameters such as working voltage and current may vary depending on the application environment and configuration. Please refer to the product manual or consult ABB technical support for detailed information.
3、 Product features
Efficiency: Through automatic synchronization function, fast and accurate generator grid connection is achieved, improving power transmission efficiency.
Security: Equipped with multiple synchronous protection functions, effectively protecting the safe and stable operation of the generator and power system.
Usability: With a user-friendly interface and monitoring functions, operators can easily grasp the system status, making it easy to operate and maintain.
4、 Installation and Maintenance
Installation: Please follow the installation guidelines provided by ABB to ensure that the modules are properly connected and securely secured.
Maintenance: Regularly check the operating status of the module, keep it clean, and avoid using it in damp, high temperature, or corrosive environments. If there are any abnormalities, please contact ABB technical support for maintenance in a timely manner.
5、 Precautions
During installation, use, and maintenance, please follow the operating guidelines and electrical safety regulations provided by ABB.
Avoid using in environments beyond the operating and storage temperature range of the module to avoid affecting its performance and lifespan.
Product image
