Product Details Introduction

97590-8 BD-PCI4PORT Data Acquisition Card Manual

1、 Product Overview

97590-8 BD-PCI4PORT is a data acquisition card produced by GE (now known as General Electric), widely used in the fields of industrial automation and control systems. The acquisition card is connected to the computer motherboard through a PCI interface, used to convert analog or digital signals from external sensors, instruments or devices into digital signals, and transmit them to the computer or control system for processing and analysis.

2、 Main features

Interface type: Adopting PCI interface type to ensure stable connection with the computer motherboard.

Input Channel: With multiple input channels, each channel can receive variable voltage signals from sensors such as thermocouples, and perform processes such as thermocouple linearization and cold end compensation.

Data conversion: Built in analog-to-digital converter (ADC), capable of converting analog signals into 16 bit signed integers, representing an accuracy of 0.125 degrees per count.

Fault handling: Supports hot spare function and allows online replacement of faulty modules. At the same time, the fault channel indicator light can display the channel status in real time, facilitating troubleshooting.

Programming support: Programmable to support multiple types of thermocouples, such as J, K, T, etc.

3、 Technical specifications

Sampling rate and resolution: The specific sampling rate and resolution depend on the configuration and model of the acquisition card, and users can choose the appropriate configuration according to application requirements.

Driver and software support: GE provides corresponding driver programs and software tools, supporting functions such as configuration, data collection, data processing, and system integration.

4、 Installation and Use

Driver installation: First, download and install the driver for the data collection card from the official GE website. After installation is completed, the computer can recognize and communicate with the data acquisition card.

Hardware connection: Connect the sensor or data source that needs to collect data to the input channel of the data acquisition card through a connecting cable. Ensure a stable and correct connection to avoid data loss or errors.

Software configuration: Use the software tools provided by GE to configure the data acquisition card, including selecting input channels, setting sampling rate and resolution parameters.

Data collection and processing: Read data from the data collection card through software tools, and process and analyze it. Users can write custom data processing programs as needed.

5、 Precautions

Before use, please carefully read this manual and operate according to relevant safety regulations.

Please ensure that the power and grounding of the data acquisition card meet the specified requirements to avoid damaging the equipment or causing safety accidents.

If you encounter any problems or malfunctions, please contact GE customer service or professional maintenance personnel for timely handling.

6、 Attachment List

Main body of data collection card

Connecting cables

Driver CD

User Manual (this manual)

Product image
