REX010 HESG324426R0001 HESG324389 Encoder Module

REX010 HESG324426R0001 HESG324389 Encoder Module

Product Details Introduction

REX010 HESG324426R0001 HESG324389 Encoder Module Manual

1、 Product Overview

REX010 HESG324426R0001 HESG324389 is a universal encoder module launched by ABB, specifically designed for industrial automation applications. This module can convert rotational motion into electrical signals and provide information such as position, velocity, and acceleration to meet the needs of control and measurement applications.

2、 Main technical parameters

Encoder type: incremental encoder

Resolution: 2500 PPR (pulse per revolution)

Pulse frequency: up to 1 MHz

Power supply voltage: 24 VDC

Working temperature: -25 ℃ to+70 ℃

External dimensions: 50 mm x 50 mm x 25 mm

Weight: 200 g

3、 Product features

High precision: Adopting high-precision optical coding technology to ensure the accuracy and reliability of measurement data.

Multifunctionality: Suitable for various industrial automation applications, such as position detection, speed control, and acceleration measurement.

Stability: Maintain stable performance over a wide temperature range and adapt to various working environments.

Easy to integrate: Using standard interfaces and protocols, it is easy to integrate with other devices and systems.

4、 Installation and Configuration

Installation: Please follow the instructions in the product manual to install and ensure that the module is properly connected and secured to the device.

Configuration: Configure through appropriate programming software or controllers, set the required parameters and functions.

5、 Usage and Maintenance

Usage: During use, please follow the operating instructions in the product manual to ensure correct use of the module and avoid overload or damage.

Maintenance: Regularly check the operation status of the module, keep it clean, and avoid the accumulation of dust and dirt. If there are any abnormalities or malfunctions, please contact technical support personnel in a timely manner for handling.

6、 Precautions

Please ensure that the module is used within the correct power supply voltage range to avoid damage to the module caused by high or low voltage.

During installation and use, please follow the safety regulations in the product manual to ensure safe operation.

Product image
