Product Details Introduction

FOXBORO P0904AK Servo Driver Manual

1、 Product Overview

FOXBORO P0904AK is a compact high-performance module designed specifically for industrial applications. It provides reliable and stable long-distance wireless communication, offering a range of control system solutions for most industries, from intelligent automation products to instrumentation and SCADA systems. This module has been widely used in various industrial environments that require high-precision control and stable communication.

2、 Product parameters

Frequency range: 2.4GHz

Transmission power:+20dBm (maximum)

Receiver sensitivity: -97dBm (typical)

Interface: UART/RS485

Power supply: 3.3VDC

Working voltage: 3.3VDC

Working temperature range: -40 ℃~+85 ℃

External dimensions: 24mm x 18mm x 4mm

3、 Storage and usage requirements

Storage requirements:

Spare modules must be stored in anti-static bags or according to the manufacturer's requirements.

The temperature and humidity of the module storage room should also meet the requirements of the manufacturing plant.

When accessing modules, anti-static measures should be taken and direct touching of the circuit board with hands is prohibited.

Pre use inspection:

Check whether the communication ports, I/O functions, and control algorithm functions meet the requirements.

Check the status of the modules on the engineer station to ensure they meet the requirements.

Load the configuration into the module and check if it is correct.

Confirmation during commissioning:

After confirming the module address and other switch settings, and confirming with the supervisor, the correct module position can be inserted.

Fill out the record card to ensure that each step of the operation complies with regulations.

4、 Regular inspections

It is recommended to inspect the P0904AK module every six months to ensure its normal operation. The inspection content includes:

The surface is clean, the printed board plug-in is free of oil stains, and there are no abnormalities after slight tapping.

The software loading and unloading test is normal, and the communication port and manual operation station are working properly.

Various analog and switch input and output channels are working normally.

Load the testing software and ensure normal operation for no less than 48 hours.

Switching test of redundant modules.

Product image
