PP835A 3BSE042234R2 touch screen
Product Details Introduction
PP835A 3BSE042234R2 Touch Screen Manual
1、 Product Overview
The PP835A 3BSE042234R2 touch screen is an operator panel provided by ABB for industrial automation control systems. It provides a user-friendly human-machine interface that allows operators to interact with control systems to monitor and control industrial processes, equipment, or systems.
2、 Main features
Human machine interface: Provides a 6.5-inch touch panel, TFT display resolution of 640x480 pixels, and supports graphic and text display. The touch function makes the operation more intuitive and convenient.
Data display: capable of displaying real-time industrial process data, graphical interface, alarm information, and other related information, providing comprehensive information support for operators.
Operation control: Operators can perform various operations through the control elements on the panel, such as starting and stopping equipment, adjusting parameters, selecting modes, etc., to achieve precise control of industrial processes.
Communication interface: Equipped with a communication interface, it can communicate with control systems and other devices to achieve data transmission and command reception.
Durability: Designed to be durable and able to withstand factors such as vibration, temperature changes, and humidity in industrial environments, ensuring long-term stable operation.
3、 Technical specifications
Model and number: Model PP835A, number 3BSE042234R2.
Display size: 6.5 inches.
Display resolution: 640x480 pixels.
Display type: TFT color touch screen.
Physical dimensions: Product net depth/length 180 millimeters, product net height 270 millimeters, product net width 76.5 millimeters.
Weight: The net weight of the product is 1.48 kilograms.
4、 Additional instructions
Protection suggestion: To protect the touch screen, it is recommended to use the RX835 touch cover.
Accessory information: Exchange part number EXC3BSE042234R2.
System compatibility: As an accessory to the control system 800xA operation panel 800, it can be integrated into ABB's automation system.
5、 Installation and Maintenance
Installation: Please follow the installation guidelines in the product manual to ensure that the touch screen is installed correctly and connected to the control system.
Maintenance: Regularly clean the surface of the touch screen to avoid using chemical cleaning agents or sharp objects to scratch the screen. If you encounter any malfunctions or issues, please contact ABB's technical support or after-sales service center.
6、 Precautions
Do not use this device in damp, high temperature, or corrosive environments.
Do not make unauthorized modifications or repairs to the device.
Product image
