NI SCXI-1160 General Switch Module Manual

1、 Product Overview

The NI SCXI-1160 Universal Switch Module is a high-performance modular switch module launched by National Instruments (NI) in the United States. This module has multiple independent channels that can be used to connect different sensors or signal sources and switch between different measurement channels.

2、 Main features

Channel quantity: According to reference article 2, the NI SCXI-1160 universal switch module has 8 independent channels, each of which supports a maximum current of 2A/channel and a maximum voltage of 250V AC/DC.

Switch type: This module uses mechanical relays as the switch type, with extremely low conduction resistance and thermal offset, and can switch, route, and control intermediate signals.

Switching speed: As mentioned in Article 3, the maximum switching speed of the SCXI-1160 switching module is 50 operations per second, ensuring support for high-speed data acquisition and control applications.

Software control: The module can be controlled through NI's hardware and software, and users can select specific measurement channels through programming to achieve flexible configuration.

Scalability: The NI module supports module stacking, allowing users to expand the number of channels as needed to meet different application requirements.

3、 Technical specifications

Model: SCXI-1160

Number of channels: 8

Maximum current: 2A/channel

Maximum voltage: 250V AC/DC

Switching rate: maximum of 50 operations per second

Driving method: voltage driven

Control method: software control

Working temperature: -40 ° C to 70 ° C

Protection level: IP65

4、 Application field

The NI SCXI-1160 universal switch module is suitable for various measurement and control applications, such as laboratory testing, data acquisition, automation, etc. When used in conjunction with SCXI chassis, the chassis can be used as a controller or switch in various types of applications, such as industrial process monitoring, production testing, and laboratory testing.

5、 Software support

NI provides specific software tools and programming interfaces, such as NI-SWITCH driver software, which is compatible with LabVIEW and LabWindows/CVI software packages for configuring, controlling, and obtaining module data.

6、 Precautions

During use, please ensure compliance with relevant safety regulations and operating guidelines.

When there is high voltage on the relay contacts, the relay switch module cannot access the analog backplane to protect it from faults.

Product image
