NI SCXI-1300 Temperature Sensor Manual

1、 Product Overview

The NI SCXI-1300 is a universal wiring terminal equipped with onboard temperature sensors, produced by National Instruments in the United States. This device aims to provide high-precision and reliable temperature measurement solutions, widely used in industrial automation, environmental monitoring, and laboratory testing fields.

2、 Main features

High precision and stability: The integrated cold end sensor on SCXI-1300 can operate with an accuracy of 1.3 ° C and a repeated accuracy of 0.5 ° C ± within the range of 0 to 50 ° C. The sensor produces an output of 10 mV/° C (from 0 to 50 ° C to 0.5 V), ensuring the accuracy and reliability of the measurement results.

Wide compatibility: SCXI-1300 can be used in conjunction with various SCXI series modules, such as SCXI-1102 series, SCXI-1104, and SCXI-1100 modules. In addition, it can also be used with SCXI-1181K and SCXI-1300 modules to provide users with more configuration options.

Easy to install and connect: The SCXI-1300 comes with a 96 pin DIN output connector that can be easily connected to the SCXI module. In addition, its design allows it to be easily installed in front of the SCXI module, making it easy for users to wiring and manage.

Electrical Safety Standards: This equipment complies with electrical safety standards such as IEC 61010-1, EN 61010-1, UL 61010-1, and CAN/CSA-C22.2 No. 61010-1, ensuring the safety of users during use.

3、 Technical specifications

Model: SCXI-1300

Accuracy: 1.3 ° C (within the range of 0 to 50 ° C)

Repetitive accuracy: 0.5 ° C ±

Sensor output: 10 mV/° C (from 0 to 50 ° C to 0.5 V)

Working temperature range: Recommended working temperature is 0 to 50 ° C, storage temperature is -20 to 70 ° C (non condensing)

Relative humidity range: 10 to 90%

Physical dimensions: 49.3 x 4.3 x 18.8 cm

4、 Installation and Use

Installation preparation: Before installing SCXI-1300, please ensure that you have prepared the necessary equipment, including SCXI-1300 wiring terminals, SCXI-1300 wiring terminal installation guide, SCXI chassis, SCXI module, SCXI module user manual, and necessary tools (such as screwdrivers, wire strippers, etc.).

Installation steps: Follow the steps in the SCXI-1300 wiring terminal installation guide for installation. Firstly, install the SCXI-1300 wiring terminals in the SCXI chassis, and then connect the SCXI module and corresponding signal lines as needed.

Instructions for use: When using SCXI-1300, please follow the operating instructions in the SCXI module user manual. You can set and control the parameters of temperature sensors to meet different application requirements through programming or configuration software.

5、 Precautions

Please ensure compliance with relevant safety regulations and operating guidelines during installation and use.

When connecting signal lines, please ensure that the pins of each channel are correctly connected to avoid damaging the equipment or affecting measurement accuracy.

Product image
