Product Details Introduction

NI SCXI-1302 Wiring Terminal Manual

1、 Product Overview

The NI SCXI-1302 wiring terminal is an important member of the SCXI series produced by National Instruments (NI). It is a 50 screw front terminal with multiple beneficial functions that help achieve seamless signal connection.

2、 Main features

Multiple signal connections: SCXI-1302 provides multiple signal connection ports for connecting measurement signals, voltage, current, etc., usually used in conjunction with SCXI-1180 feedthrough boards.

Shielding design: This wiring terminal adopts a shielding design to ensure fast and reliable signal connection.

Installation options: Provides two options: rack installation and DIN rail installation, making it convenient for users to install according to their actual needs.

Stress relief fixture: In order to ensure that the signal wire is firmly in place, this wiring terminal is also equipped with a stress relief fixture.

DC suppression capability: The DC suppression capability of SCXI-1302 is ± 50 VDC.

3、 Technical specifications

Model: SCXI-1302

Part number: 777687-02

Maximum magnetic field wire gauge: 26-16AWG

Coupling method: DC

Transition frequency: 0.16 Hz 1-pole RC

Usage software: NIDAQmx driver software (compatible with LabVIEW, LabWindows/CVI, ComponentWorks, etc.)

4、 Installation and Configuration

Required items for installation: installation guide, wire insulation stripping pliers, wire cutting pliers, long nose pliers, 1/4 inch and 1/8 inch flat head screwdrivers, Philips screwdrivers 1 and 2, SCXI chassis, and SCXI-1180 feeder board.

Configuration: Use the Measurement&Automation Explorer (MAX) tool to configure the device.

5、 Application field

SCXI-1302 is widely used in laboratory testing, data acquisition, sensor measurement, automation control and other fields, and can be used in conjunction with other modular measurement system modules, such as data acquisition modules, signal conditioning modules, etc.

6、 Electrical safety standards

NI SCXI-1302 complies with the following electrical safety standards: IEC 61010-1, EN 61010-1, UL 61010-1, and CSA 61010-1.

7、 Precautions

During installation and use, please follow relevant safety regulations and operating guidelines.

Please ensure to use the correct installation methods and tools to avoid damaging the equipment or affecting performance.

Product image
