HONEYWELL 05701-A-0301 Channel Control Card

HONEYWELL 05701-A-0301 Channel Control Card

Product Details Introduction

HONEYWELL 05701-A-0301 Channel Control Card Manual

1、 Product Overview

HONEYWELL 05701-A-0301 is a single channel loop input control card launched by Honeywell Corporation, mainly used for measuring and controlling analog signals in various industrial processes. This product has been widely used in the field of industrial control due to its high precision, high efficiency, ease of use, and scalability.

2、 Product features

Single channel design: HONEYWELL 05701-A-0301 is a single channel design that can control or monitor a specific parameter or process, such as temperature, pressure, flow rate, etc.

High precision measurement: Provides leading measurement technology to ensure precise process control, with an accuracy of ± 0.1% of full scale.

High efficiency: Adopting high-quality creativity and design to ensure long-term stable operation.

Easy to use: Provides simple installation and configuration, making it convenient for users to operate.

Strong scalability: Compatible with other Honeywell control systems to meet various application requirements.

Real time control and data feedback: Usually able to provide real-time control and data feedback to ensure rapid response to the system.

3、 Product parameters

Input type: Analog input.

Input signal: Supports multiple signal types such as current, voltage, thermocouple, thermal resistance, etc.

Input range: can be configured as needed.

Accuracy: ± 0.1% of full scale.

Resolution: 0.01% of full scale.

Response time:<2 seconds.

Power supply voltage: 24V DC.

Working temperature: -40 ° C to+85 ° C.

Storage temperature: -55 ° C to+125 ° C.

Protection level: IP67 level.

4、 Product specifications

Size: 90mm x 60mm x 25mm.

Weight: 150 grams.

Material: Magnesium alloy.

5、 Application field

HONEYWELL 05701-A-0301 Channel Control Card is widely used in the following industries and fields:

The oil and gas industry.

Chemical production.

Electric power industry.

The food and beverage industry.

Water and wastewater treatment.

6、 Installation and Maintenance

Installation: Please follow the installation steps in the product manual to ensure that the power connection is correct and the installation position is appropriate.

Maintenance: Regularly check the connection and working status of the control card. If there are any abnormalities, please contact professional personnel in a timely manner for handling.

7、 Safety precautions

Do not use this product beyond the specified working and storage temperature range.

Please ensure that the power is disconnected during installation and maintenance to avoid the risk of electric shock.

Please do not disassemble or modify the internal structure of this product without authorization, as this may affect its performance and safety.

The above is a detailed explanation about the HONEYWELL 05701-A-0301 channel control card

Product image
