PACIFIC 6410-024-N-N-N Stepper Motor Driver Manual

1、 Product Overview

PACIFIC 6410-024-N-N-N stepper motor driver is a high-performance driver that belongs to the servo system product series of Pacific Scientific Company. This drive is designed to provide dynamic solutions for industry or engineers, and is widely used in fields such as X-Y workbenches and slides, packaging systems, labeling machines, and robotic machinery.

2、 Product features

High performance: The PACIFIC 6410-024-N-N-N stepper motor driver has the characteristics of high dynamic response and precise control, which can meet the needs of various complex industrial applications.

Reliability: The driver design considers multiple safety factors, including automatic cyclic power supply function, which can clear errors in the event of errors or excessive power supply, ensuring the safe operation of the equipment.

High power: The driver has a power level of 7.1 A peak, 5 A rms, and a voltage range of 24-75 Vdc, suitable for various load scenarios.

Noise cancellation: MOSFET power devices allow for chopping frequencies up to 20 KHz, which helps to eliminate noise and improve the smoothness of equipment operation.

High resolution compensation: Pacific Science provides high-resolution compensation by ensuring that each motor winding matches the rated output of the product, ensuring precise control of the equipment.

3、 Technical parameters

Model: 6410-024-N-N-N

Power level: 7.1 A peak, 5 A rms

Voltage range: 24-75 Vdc

Radiator, connector kit, and cover options: None

Driver family type: stepper drive (6000)

Chopping frequency: up to 20 KHz

4、 Installation and debugging

When installing and debugging the PACIFIC 6410-024-N-N-N stepper motor driver, it is recommended to follow the following steps:

Determine installation location: Select a suitable installation location based on equipment requirements to ensure stable and reliable connections between the driver, motor, controller, and other components.

Connect the power supply and controller: Connect the power supply and controller correctly according to the wiring diagram to ensure stable and safe power supply.

Install driver: Install the driver correctly on the device and connect it to the motor and controller.

Perform basic debugging: Check whether the power supply and controller are normal, send pulse signals to the motor through the controller, observe the movement of the motor, and check for any abnormalities.

Fine tuning: Adjust the parameters of the driver according to actual needs, such as current limitation, micro step subdivision, etc., to optimize the performance and control accuracy of the motor.

5、 Maintenance and troubleshooting

If any abnormalities or malfunctions are found in the drive during use, please follow the following steps for maintenance and troubleshooting:

Check the power supply and connections: First, check if the power supply is normal and if all connections are firm and reliable.

Check the drive indicator light: Based on the status of the drive indicator light, determine if there is a fault, such as the power light not turning on, TM light not turning on, or constantly turning on.

Refer to the fault code table in the manual for troubleshooting if the driver displays a fault code.

Replace faulty components: If it is determined that a component is faulty, please replace it in a timely manner to ensure the normal operation of the equipment.

6、 Safety precautions

Do not use this drive in damp, high temperature, high pressure, or strong magnetic field environments.

Do not disassemble or modify the internal structure of the drive without authorization.

When using this drive, please ensure that the connection is correct and stable to avoid short circuits or overloads.

The above is the instruction manual for PACIFIC 6410-024-N-N-N stepper motor driver

Product image
