TRICONEX AI3351 Analog Input Module

TRICONEX AI3351 Analog Input Module

Product Details Introduction

TRICONEX AI3351 Analog Input Module Manual

1、 Product Overview

TRICONEX AI3351 Analog Input Module is a high-precision and highly reliable analog input module manufactured by TRICONEX company. This module adopts advanced microprocessor technology and programmable logic controllers, which can collect and process analog signals in real time. It is widely used in industrial control, automation systems, instruments, and data acquisition fields.

2、 Product features

High precision: The AI3351 module adopts a 16 bit sampling resolution, with a linear error of 0.1% and a stability of 0.01%/℃, ensuring high accuracy in data acquisition.

High reliability: The module has multiple protection functions, effectively preventing electromagnetic interference and overload, ensuring stable operation in industrial environments.

Flexibility: Supports a 4-20mA analog signal range and can adjust the analog output range according to actual needs.

High adaptability: The working temperature range covers -40 ℃ to+75 ℃, the storage temperature range is -40 ℃ to+85 ℃, and the relative humidity is 5% to 95% RH (non condensing), suitable for various industrial environments.

3、 Technical specifications

Model: AI3351

Power supply: 24VDC

Number of channels: 8

Output type: Analog quantity

Signal range: 4-20mA

Sampling resolution: 16 bits

Linear error: 0.1%

Stability: 0.01%/℃

Isolation voltage: 1500VAC

4、 Application field

The TRICONEX AI3351 analog input module can be widely used in the following fields:

industrial control

automatic system

instrument

data acquisition

5、 Installation and Use

Installation: Ensure that the power supply is connected and meets the product's power supply specifications. Connect the sensor signal line to the AI3351 channel input port.

Usage: Adjust the analog output range according to actual needs. Start the device to start using it.

6、 Security and Maintenance

Safety: During installation, configuration, and maintenance, please ensure that the power is disconnected to avoid the risk of electric shock. Modules should be avoided from use in humid, high temperature, high pressure, or strong magnetic field environments.

Maintenance: Regularly check the connection and working status of the module to ensure its normal operation. If there are any abnormalities, please refer to the fault diagnosis section in the product manual for troubleshooting and repair.

Product image
