BCU-12 3AUA0000110430 Industrial Automation Module

Product Details Introduction

BCU-12 3AUA000010430 Industrial Automation Module Manual

1、 Product Overview

BCU-12 3AUA000010430 is a high-performance industrial automation module designed specifically to meet the needs of various industrial automation applications. It combines advanced control technology and reliable hardware design to provide users with efficient, stable, and easily integrated industrial automation solutions.

2、 Product features

High response frequency: The highest response frequency of BCU-12 3AUA0000110430 can reach 200Kpps, ensuring precise control signals in high-speed motion control.

High performance stepper driver: As a two-phase stepper driver, this module is suitable for various models of two-phase hybrid stepper motors with 6 or 8 output lines, current below 3A, and an outer diameter of 42-86mm. It adopts a bipolar constant current chopping method internally, making the motor run more smoothly.

Intelligent control: When the step pulse stops for more than 100ms, the coil current automatically halves, effectively reducing motor overheating and driver heating. At the same time, there are 12/8 equal angle constant torque subdivisions, with a maximum of 64 subdivisions, improving the operating accuracy of the stepper motor.

Widely applicable: single power input, voltage range DC12-40V, continuously adjustable driving current from 0.0A/phase to 3.0A/phase, capable of driving any two-phase hybrid stepper motor with a phase current below 3.0A.

Network communication capability: This module also has industrial grade Ethernet switch function, providing multiple electrical and optical ports, supporting multiple network redundancy protocols, and ensuring the reliability and stability of network communication.

3、 Technical indicators

Drive voltage: DC12-40V

Adapted motor: Two phase hybrid stepper motor with 6 or 8 output lines, current below 3A, outer diameter 42-86mm

Response frequency: up to 200Kpps

Subdivision setting: 12/8 equal angle constant moment subdivision, with a maximum of 64 subdivisions

Communication interface: 6 10/100Base-T (X) electrical ports and 2 optical ports (supporting multiple rates and protocols)

4、 Typical applications

The BCU-12 3AUA000010430 industrial automation module is suitable for various industrial automation scenarios that require high-precision and high-speed control, such as engraving machines, laser marking machines, laser engraving machines, small electronic devices, packaging machines, etc.

5、 Installation and debugging

During the installation and debugging process, please ensure to follow the instructions in the product manual, including equipment inspection, power connection, parameter adjustment, communication testing, and other steps. In addition, attention should also be paid to equipment safety protection and electromagnetic compatibility issues.

6、 Precautions

During use, please ensure that the power supply voltage is stable to avoid damage to the equipment caused by high or low voltage.

When debugging and maintaining, please ensure that the power is disconnected and follow the relevant safety operating regulations.

Product image
