3BSE013252R1 CI830 Main Fieldbus Control Card

3BSE013252R1 CI830 Main Fieldbus Control Card

Product Details Introduction

3BSE013252R1 CI830 Main Fieldbus Control Card Instruction Manual

1、 Product Overview

3BSE013252R1 CI830 main fieldbus control card is a high-performance control card launched by ABB, widely used in industrial automation and control system fields. It is based on advanced bus control technology, which can achieve efficient and reliable control of field devices, and supports multiple bus protocols and interfaces.

2、 Product features

Multi communication interface support: In addition to the integrated communication function on the CPU, each CPU also supports up to 4 communication extension interface modules. These communication interfaces can be extended to any standard bus protocol module, such as Profibus DP, DeviceNet, CANopen, and Ethernet.

Flexible configuration: The CPU motherboard has three different specifications based on the number of communication interfaces, each with 1, 2, or 4 communication slots. Users can flexibly configure according to their actual needs.

Powerful input and output capabilities: The I/O modules include two types: analog and switching. It can expand up to 10 I/O modules locally on the CPU (firmware version V1.2 or above), and distributed substations can expand up to 7 I/O modules.

Pre wiring function: The I/O motherboard is divided into two different voltage levels of 24VDC and 230VAC, providing two wiring methods: screw and spring. When there is no input/output module, pre wiring function can be achieved.

3、 Technical specifications

Model: 3BSE013252R1 CI830

Brand: ABB

Communication interface: Supports up to 4 communication extension interface modules, which can be extended to bus protocols such as Profibus DP, DeviceNet, CANopen, and Ethernet.

I/O module expansion: Up to 10 I/O modules can be expanded locally on the CPU, and up to 7 I/O modules can be expanded on distributed substations.

I/O motherboard: two voltage levels of 24VDC and 230VAC, with two wiring methods of screw and spring.

4、 Installation and Configuration

Installation: Please follow the instructions in the product manual to install and ensure the correct connection and fixation of the card with the system.

Configuration: According to system requirements, set the parameters of the card through corresponding configuration tools, including communication protocol, I/O module configuration, etc.

5、 Maintenance and troubleshooting

Regular inspection: Regularly check the connection and working status of the card components to ensure their stable operation.

6、 Precautions

During installation, configuration, and maintenance, please ensure compliance with relevant safety operating procedures to avoid damage to equipment and personnel.

Do not use this card in damp, high temperature, high pressure, or strong magnetic field environments to ensure its normal operation and stable performance.

Product image
