EI813F 3BDH000022R1 Ethernet module

EI813F 3BDH000022R1 Ethernet module

Product Details Introduction

EI813F 3BDH000022R1 Ethernet Module Manual

1、 Product Overview

EI813F 3BDH000022R1 is a powerful and stable Ethernet module produced by ABB, specifically designed for industrial automation systems. This module supports the IEEE802.3 Ethernet standard and provides communication (10MBit) that complies with the 10BaseT standard, with a transmission rate of up to 10 MBit/s, ensuring fast and accurate data transmission in the network.

2、 Product features

High speed communication performance: Supports IEEE802.3 Ethernet standard, with a transmission rate of 10 MBit/s, ensuring efficient data transmission.

Direct memory access: With the function of direct memory access to main memory, it reduces the CPU's overhead in processing network communication and improves overall system performance.

Battery backup function (optional): Provides redundant power to the main memory, ensuring that critical data is not lost in the event of a system power failure.

Easy to integrate: The design is flexible and easy to integrate with control systems such as PLC and DCS, reducing the difficulty and cost of system integration.

Status indication: The integrated LED indicator light on the front panel clearly displays the communication status, making it convenient for users to quickly understand the working status of the module.

High compatibility: Supports multiple network protocols and interface standards, enabling cross platform data exchange and communication.

High security: Encryption and verification mechanisms are used during data transmission to ensure the security and integrity of the data.

3、 Application field

Industrial automation: As a part of control systems, it is used for data communication and information transmission to achieve monitoring and control of industrial equipment and processes.

Data communication: widely used in the industrial field for data communication between devices, achieving real-time monitoring and data exchange.

Remote control and monitoring: Implement control and monitoring of remote devices and processes, especially suitable for cross regional or distributed control systems.

Data collection and processing: Summarize and process data from different devices and sensors to provide comprehensive information and decision support.

Building automation: In building automation systems, it is used to control and manage building facilities such as lighting, air conditioning, security, etc.

Energy management: In the energy management system, control and monitoring of energy equipment are achieved to improve energy utilization efficiency.

4、 Technical specifications

Product type: Ethernet module

Communication standard: IEEE802.3, 10BaseT

Transmission rate: 10 MBit/s

Interface form: Ethernet interface (specific form not provided in detail)

Power supply voltage: may vary depending on specific application (such as 24V DC)

Power consumption: 2.5 W (or different depending on specific model)

Working temperature: -40 ℃~+70 ℃

Storage temperature: -40 ℃~+85 ℃

Humidity: 5%~95% RH

5、 Installation and Maintenance

Installation: Please follow the instructions in the product manual to install and ensure that the module is properly connected to the system.

Maintenance: Regularly check the working status of the module and keep it clean and dry. If there are any abnormalities, please contact professional technical personnel for maintenance in a timely manner.

6、 Precautions

Do not use the module within the specified working environment temperature and humidity range.

If there is a module malfunction or abnormal situation, please cut off the power in a timely manner and contact professional technical personnel for maintenance.
