HE700GEN200 Network Interface Module

HE700GEN200 Network Interface Module

Product Details Introduction

HE700GEN200 Network Interface Module Manual

1、 Product Overview

HE700GEN200 is a network interface module produced by General Electric (GE), designed specifically for industrial automation and control systems. This module has powerful communication functions, supports multiple communication protocols and interfaces, and can achieve efficient and stable data transmission and exchange.

2、 Product features

Communication interface: HE700GEN200 supports multiple communication interfaces, such as Ethernet, serial communication, etc., making it convenient to connect different devices and networks.

Protocol support: The module supports multiple communication protocols, such as Modbus, Ethernet/IP, Profibus, etc., to meet different communication needs.

Data exchange: allows for data exchange within the control system, enabling real-time data monitoring, data collection, control command sending, and other functions.

Data processing: With data processing and conversion functions, it can process and convert the received data to meet the communication needs between different devices.

User friendliness: With a user-friendly configuration interface, it is easy for users to set up and configure. At the same time, it supports programming functions and allows users to customize communication and control logic.

Diagnosis and monitoring: With diagnostic and monitoring functions, it can monitor communication status, data transmission status, etc., and provide relevant diagnostic information.

Reliability: The module adopts high-quality materials and manufacturing processes, with high stability and reliability, ensuring the accuracy and stability of communication.

3、 Technical specifications

Power input: 100-240V AC

Maximum current: 10A

Working temperature: -40 ° C to 70 ° C

Storage temperature: -40 ° C to 85 ° C

Protection level: IP20

Dimensions: 70mm x 130mm x 80mm

Weight: 0.5kg

Installation method: DIN rail installation

4、 Application field

The HE700GEN200 network interface module is widely used in the field of industrial automation control, such as factory automation, energy management, manufacturing, etc. It can seamlessly connect with various devices and systems, achieving collaborative work and automated control between devices.

5、 Installation and Configuration

Installation: After confirming that the power input voltage meets the requirements, install the product on the DIN rail. Ensure that the power cord is connected correctly.

Configuration: Set up and configure modules through a user-friendly configuration interface. Select communication protocols, interfaces, and other parameters based on actual needs.

6、 Precautions

Do not use the module within the specified working environment temperature and humidity range.

During installation, configuration, and maintenance, please follow relevant safety operating procedures to ensure the safety of personnel and equipment.

7、 Maintenance and upkeep

Regularly check the working status of the module and keep it clean and dry. If there are any abnormalities, please cut off the power in a timely manner and contact professional technical personnel for maintenance.

Product image
