IC690RFH008 Digital Expansion Module

IC690RFH008 Digital Expansion Module

Product Details Introduction

IC690RFH008 Digital Expansion Module Manual

1、 Product Overview

IC690RFH008 is a digital expansion module produced by General Electric (GE), specifically designed for use in VersaMax micro programmable logic controllers (PLCs). This module operates in the ultra-high frequency (UHF) band and supports reading and writing data through radio frequency identification (RFID) technology. It is widely used in fields such as supply chain management, asset tracking, and inventory management.

2、 Product features

Radio frequency communication: Using radio frequency communication to achieve efficient data transmission and communication with other devices.

Programmability: With programmable features, it can be flexibly configured according to individual or system requirements.

Wireless connection: Data exchange with PLC through wireless connection without physical connection, simplifying system wiring.

Long reading distance: Working in the UHF band, the reading distance can reach up to ten meters, suitable for various distance requirements scenarios.

High accuracy: equipped with two antenna ports, which can connect antennas to improve reading range and accuracy.

Easy to install and configure: Comes with user manual and software tools, making the installation and configuration process simple and fast.

Supports multiple protocols: communicates with RFID tags using the EPC Global Class 1 Gen 2 protocol, with strong compatibility.

3、 Technical specifications

Working frequency band: Ultra High Frequency (UHF)

Communication protocol: EPC Global Class 1 Gen 2, etc

Antenna ports: two

Reading distance: up to ten meters

Connection method: serial or Ethernet interface

Protection level: determined based on specific application scenarios and configurations

4、 Application field

The IC690RFH008 digital quantity expansion module is suitable for various scenarios that require efficient and accurate reading and writing of RFID tag data, such as supply chain management, asset tracking, inventory management, industrial automation, etc.

5、 Installation and Configuration

Installation: Select the appropriate installation location and method based on the user manual and actual on-site conditions to ensure the stability and reliability of the module.

Configuration: Use matching software tools for module configuration, set key parameters such as communication parameters and reading range to meet actual needs.

6、 Maintenance and upkeep

Regular inspection: Regularly check the working status of the module to ensure its normal operation.

Cleaning and maintenance: Keep the module clean and dry to avoid dust and moisture affecting the module.

Fault diagnosis: If a module malfunctions, troubleshooting and handling can be carried out according to the fault diagnosis methods in the user manual.

Product image
