Product Details Introduction

PROSOFT PTQ-PDPMV1 Network Communication Processor Block Manual

1、 Product Overview

PROSOFT PTQ-PDPMV1 is a network communication processor block designed specifically for industrial control systems, used for data communication and integration between different networks. It can act as a gateway or protocol converter, enabling devices of different types or brands to interconnect and exchange data.

2、 Main features

Protocol conversion: Supports multiple communication protocols, including industrial Ethernet (such as Ethernet/IP, Modbus TCP/IP), serial communication (such as Modbus RTU, DF1), fieldbus (such as Profibus, DeviceNet), etc. It can convert data between different protocols.

Data integration: The ability to integrate data from different networks or devices into a unified control system, facilitating centralized monitoring and control of the entire system.

Gateway function: It can serve as a gateway to transmit data from on-site devices to the upper level monitoring system or cloud, achieving remote monitoring and management.

Real time data processing: With real-time data processing capabilities, including data collection, processing, filtering, conversion and other operations, it meets the needs of real-time control and monitoring.

High reliability: Using high-quality materials and components, and undergoing strict production processes and quality control, it has high reliability and stability.

Easy to configure and manage: Provides easy-to-use configuration software and interface, making it convenient for users to set parameters, configure functions, and debug programs.

Flexible scalability: Adopting modular design, it facilitates users to choose different input/output modules and functional modules for expansion and maintenance according to their actual needs.

3、 Technical specifications

Supported communication protocols: Ethernet/IP, Modbus TCP/IP, Modbus RTU, DF1, Profibus, DeviceNet, etc

Data integration capability: able to integrate data from different sources into a unified control system

Real time data processing capability: supports operations such as data collection, processing, filtering, and conversion

Working environment temperature: 32 ° F to 140 ° F (0 ° C to 60 ° C)

Storage temperature: -40 ° F to 185 ° F (-40 ° C to 85 ° C)

Relative humidity: 5% to 95% (non condensing)

Vibration and shock: Meet the vibration and shock requirements of the industrial environment

4、 Application field

PROSOFT PTQ-PDPMV1 is widely used in the field of industrial automation, including manufacturing, energy, chemical, logistics and other industries. It is an important component of modern industrial control systems to achieve data communication and integration between different devices.

5、 Installation and Configuration

For specific installation and configuration steps, please refer to the official installation guide and configuration software manual provided by PROSOFT. Usually, users need to use the configuration software provided by PROSOFT to set module parameters and configure functions. During the installation process, please ensure to follow the requirements in the guide to ensure the stable operation and performance of the module.

Product image
