SD812F 3BDH000014R1 Control Output Board

SD812F 3BDH000014R1 Control Output Board

Product Details Introduction

SD812F 3BDH000014R1 Control Output Board Manual

1、 Product Overview

SD812F 3BDH000014R1 is a high-performance control output board launched by ABB, belonging to the programmable controller series in industrial automation products. It is mainly used to control industrial processes and machines, achieving precise data processing and logical control.

2、 Main technical parameters

Brand and model: ABB, SD812F 3BDH000014R1

Input/output points: The number of I/O points reaches 24, including 16 word inputs and 16 word outputs.

Working voltage: 220V

Output frequency: 100Hz

Processing speed: up to 550 μ s

Program capacity: 300

Data capacity: 200

Input voltage and current: 24 V DC ± 20%, maximum input current is 5 mA (or 0.5 A, depending on application)

Input/Output Type: Supports single ended and differential input types, with relay output type

3、 Functional characteristics

High speed processing capability: SD812F 3BDH000014R1 has powerful data processing capabilities, which can efficiently process large amounts of data and meet complex control requirements.

Multiple communication interfaces: Supports multiple communication interfaces such as Ethernet and serial communication, facilitating data exchange and communication with other devices.

Programmability: As a programmable controller, SD812F 3BDH000014R1 can be programmed and configured according to the actual needs of users, achieving specific control logic and functions.

Protection and monitoring functions: Built in multiple protection and monitoring functions to ensure the safety and stability of the device during operation.

4、 Installation and Configuration

Installation: Please follow the instructions in the product manual for installation, ensure that the control output board is correctly connected to the system, and pay attention to heat dissipation and ventilation requirements.

Configuration: Use programming tools provided by ABB (such as Control Builder M) for programming and configuration to meet specific application requirements. During the configuration process, please pay attention to requirements such as impedance matching, voltage range, and signal shielding to ensure the stability and accuracy of signal transmission.

5、 Maintenance and upkeep

Regular inspection: Regularly inspect the appearance and connection status of the control output board to ensure that there is no damage or looseness. At the same time, check the connection of the power and signal lines to ensure reliable connection and no faults such as short circuits or open circuits.

Cleaning: Keep the control output board clean and dry to avoid dust and moisture affecting the equipment. If necessary, dry compressed air can be used for cleaning.

Safe operation: During installation, configuration, and maintenance, please follow relevant safety operation regulations to ensure the safety of personnel and equipment.

6、 Precautions

Do not use the control output board within the specified working environment temperature and humidity range.

Do not make unauthorized modifications or modifications to the control output board to avoid affecting its normal operation and performance.

If you encounter any problems or malfunctions during use, please contact ABB's technical support team or relevant maintenance personnel in a timely manner for handling

Product image
