PP835 3BSE042234R1 operation panel

PP835 3BSE042234R1 operation panel

Product Details Introduction

PP835 3BSE042234R1 Operation Panel Manual

1、 Product Overview

PP835 3BSE042234R1 is a Panel 800 series touch screen operation panel launched by ABB Group, designed specifically to meet the human-machine communication needs in industrial automation and control systems. This control panel allows operators to easily interact and monitor with the control system through an intuitive graphical user interface (GUI).

2、 Technical specifications

Model: PP835 3BSE042234R1

Brand: ABB

Control principle: Object oriented working method, easy to understand and use

Usage: Interface for automatic voltage regulation, industrial automation, and control systems

Range: 100-420 (specific range application not provided in detail)

Accuracy: 0.1-2.2 (specific accuracy application not provided in detail)

Specification and size: 20022050mm

Power supply: Depending on specific application configuration

Communication interfaces: Ethernet, serial interfaces, etc. (supporting multiple communication protocols and interfaces)

3、 Functional characteristics

Display and Control: Supports text display and control, including dynamic indications, time channels, alarms, and recipe processing.

Configuration method: Use Panel Builder 800 configuration tool to configure on a personal computer, then transfer and store the project in the operation panel.

Device connection: can be connected to various types of automation devices, such as programmable logic controllers, servos, or drives.

Graphical representation: Provides an intuitive graphical user interface that supports graphical representation and real-time data monitoring.

Customized design: The touch screen interface can be customized according to specific application requirements to meet specific control and monitoring requirements.

Durability and Safety: Touch screens used in industrial environments need to be durable, and the PP835 3BSE042234R1 operation panel can resist vibration, temperature changes, and other harsh conditions. At the same time, the operation panel has security features to ensure that only authorized operators can access and control the system.

4、 Installation and Configuration

Installation: Please follow the instructions in the product manual for installation to ensure that the operation panel is stably and reliably installed in the control cabinet or equipment.

Configuration: Use Panel Builder 800 configuration tool for configuration, including setting input and output parameters, control logic, communication protocol, etc. Please refer to the product manual or consult the supplier for specific configuration methods.

5、 Usage and Maintenance

Usage: Please follow the instructions in the product manual to avoid exceeding the working range and limitations of the product. If any abnormal situations or malfunctions are found during use, please contact the supplier or professional technical personnel for timely handling.

Maintenance: Regularly inspect and maintain the operation panel, including cleaning, tightening connectors, checking power and signal circuits, etc. If necessary, troubleshooting and repair can be carried out according to the instructions in the product manual.

6、 Precautions

Do not use the operation panel under environmental conditions that exceed the product specifications, as this may damage the equipment or affect performance.

Do not make unauthorized modifications or alterations to the control panel to avoid affecting its normal operation and performance.

During installation, configuration, and use, please follow relevant safety operating procedures to ensure the safety of personnel and equipment.

Product image
