RELIANCE Y-3023-2-H00AA servo motor

RELIANCE Y-3023-2-H00AA servo motor

Product Details Introduction

RELIANCE Y-3023-2-H00AA Servo Motor Manual

1、 Product Overview

RELIANCE Y-3023-2-H00AA is a high-performance brushless servo motor designed specifically for applications that require high-precision motion control and fast response. This servo motor is widely used in industrial automation, robotics technology, precision machinery, and other fields due to its precise control, high responsiveness, and programmability.

2、 Main technical parameters

Model: Y-3023-2-H00AA

Brand: RELIANCE

Motor winding: 230V ac

Large radial (FR) load: 35 kg

High working speed: 4500 rpm

Number of poles: 8

Thermal resistance: 0.85 C/watt

Optical encoder line count: 2000 P/R

Encoder power supply: 5V DC voltage

3、 Functional characteristics

Precision control: The RELIANCE Y-3023-2-H00AA servo motor can achieve precise position, speed, and acceleration control, meeting the needs of various complex applications.

Closed loop control: Adopting a closed-loop control system, real-time monitoring of motion status is achieved through feedback mechanisms (such as encoders) to ensure higher control accuracy.

High responsiveness: With fast response speed, it can complete position or speed changes in a short period of time, suitable for applications that require rapid action.

Programmability: It can adjust parameters and control logic programming according to specific applications, and flexibly adapt to various control needs.

Smooth motion: achieving smooth motion, avoiding vibration and vibration, and ensuring high-quality motion performance.

High torque density: Provides a larger output torque in a relatively small size to meet the requirements of high load applications.

Position retention ability: able to maintain low position errors even when stopping motion, ensuring accuracy of movement.

4、 Application field

RELIANCE Y-3023-2-H00AA servo motors are widely used in complex positioning and speed applications on industrial machines, as well as acceleration control. It is suitable for servo motors with larger frame sizes in the Y series of light industry, especially in situations where high precision, high responsiveness, and programmability are required.

5、 Usage and Maintenance

Installation: Please follow the instructions in the product manual for installation to ensure that the motor is stably and reliably fixed in the equipment or control cabinet.

Connection: When connecting to the servo drive, please ensure that the connecting cable is as short as possible and use a rigid connection to prevent sliding and shaft degradation.

Working environment: Please use in standard industrial environments and avoid exposure to high humidity or high ambient temperatures.

Maintenance: Regularly inspect the appearance and connection status of the motor, keep it clean and dry. If necessary, troubleshooting and repair can be carried out according to the instructions in the product manual.

6、 Precautions

Do not use the motor under environmental conditions that exceed the product specifications, as this may damage the equipment or affect performance.

Do not make unauthorized modifications or modifications to the motor to avoid affecting its normal operation and performance.

During installation, configuration, and use, please follow relevant safety operating procedures to ensure the safety of personnel and equipment.

Product image
