Modicon NW-BM85C002 Dual System Processor
Product Details Introduction
Modicon NW-BM85C002 Dual System Processor Manual
1、 Product Overview
The Modicon NW-BM85C002 is a dual system processor produced by Schneider Electric and designed specifically for the industrial automation field. This processor adopts high-performance optoelectronic devices, which have characteristics such as high transmission rate, long transmission distance, and low power consumption. At the same time, it adopts a strict quality control system to ensure high reliability. The operation of NW-BM85C002 is simple, convenient to use, and can meet the needs of various industrial automation applications.
2、 Main technical parameters
Model: NW-BM85C002
Brand: Schneider
Power supply and installation method: Supports 115/220VAC or 24VDC, suitable for panel or rack installation
Communication interface: Modbus Plus interface, supporting high-speed peer-to-peer communication network
Communication speed: up to 1 megabaud
3、 Functional characteristics
High performance: Using high-performance optoelectronic devices, it provides high transmission rates and long transmission distances, while reducing power consumption.
High reliability: Through a strict quality control system, ensure the high reliability of products.
Easy to use: Simple to operate, easy to configure and use.
Communication capability: Supports Modbus Plus interface, enabling high-speed peer-to-peer communication networks, providing convenient communication for CPUs, hosts, and other data resources.
4、 Application field
The Modicon NW-BM85C002 dual system processor is suitable for various industrial automation control systems, including interlocking operations on the control network, data acquisition, software uploading and downloading, remote online programming, connection with the operator interface, and data collection from the host. It can handle real-time communication of control devices, such as I/O and frequency converters, and its performance is not affected by load or communication volume.
5、 Installation and Configuration
Installation: Please follow the instructions in the product manual to correctly install the NW-BM85C002 dual system processor in the control cabinet or device, ensuring proper connection with other devices and systems.
Configuration: Use appropriate configuration tools or software to configure the processor as necessary, including setting parameters, addresses, communication protocols, etc.
6、 Maintenance and upkeep
Regular check: Regularly check the working status of the processor to ensure its normal operation.
Cleaning: Regularly clean the casing and connectors of the processor to prevent the accumulation of dust and dirt.
Technical Support: If you have any questions or need assistance, please contact Schneider Electric's technical support team.
7、 Precautions
Do not use the processor under environmental conditions beyond the product specifications to avoid damaging the device or affecting performance.
Do not make unauthorized modifications or modifications to the processor to avoid affecting its normal operation and performance.
During installation, configuration, and use, please follow relevant safety operating procedures to ensure the safety of personnel and equipment.
Product image
