NI PXI-7344 servo controller

Product Details Introduction

NI PXI-7344 Servo Controller Manual

1、 Product Overview

NI PXI-7344 is a high-performance servo controller launched by National Instruments (NI) and belongs to the PXI series of products. This controller is designed specifically for motion control and servo drive applications, providing precise motion control solutions.

2、 Main features

Multi axis control: NI PXI-7344 supports multi axis servo control, which can simultaneously control multiple servo motors or actuators. It provides multiple independent servo axis channels, each of which can be independently configured and controlled.

High precision control: This controller has high-precision motion control capabilities and can achieve precise control of servo motor position, speed, and acceleration. It supports closed-loop control, which adjusts and stabilizes the control system in real-time through feedback signals.

Communication interface: The PXI-7344 controller is connected to a computer or upper computer through various communication interfaces, such as PCIe, PXIE, etc. This makes data exchange and communication with other controllers, sensors, and external devices very convenient.

Configuration and programming: With NI's motion control software and programming tools such as LabVIEW and Motion Assistant, PXI-7344 can be easily configured and programmed. These tools simplify the setup, debugging, and programming process of the controller, improving work efficiency.

Scalability: Based on the PXI platform, the NI PXI-7344 controller has strong scalability. Through a slot architecture, it is easy to add other modules and devices to meet the needs of specific applications.

3、 Technical specifications

Applicable buses: PCI, PXI, and 1394 bus computers

Control mode: supports multiple modes such as position, speed, and force control

Feedback signal: supports orthogonal encoder or analog input for position and speed feedback

Instruction output: Provides analog instruction output, with an industrial standard range of ± 10V

4、 Application scenarios

The NI PXI-7344 servo controller is suitable for various industrial and scientific applications that require precise motion control, including laboratory research, production line automation, etc.

5、 Software support

Before installing the 7344 controller, please install FlexMotion software and install the Motion VI library as appropriate. These software tools provide powerful support for controller configuration, programming, and debugging.

6、 Precautions

Misuse of equipment may cause danger and may compromise the built-in safety protection of the device.

If the device is damaged, please turn off the device and do not use it until service trained personnel have checked its safety.

If necessary, send the equipment back to National Instruments for repair.

7、 Summary

The NI PXI-7344 servo controller is a powerful and high-performance servo controller with high precision, multi axis control, and easy programming. It is suitable for various industrial and scientific applications that require precise motion control, and is an ideal choice for laboratory research and production line automation.

Product image
