PROSOFT 5302-MBP-MCM4 Gateway Module

PROSOFT 5302-MBP-MCM4 Gateway Module

Product Details Introduction

PROSOFT 5302-MBP-MCM4 Gateway Module Manual

1、 Product Overview

PROSOFT 5302-MBP-MCM4 is an input-output module designed specifically for industrial automation and control systems, aimed at achieving functions such as data acquisition, control, monitoring, and communication to meet various industrial automation needs. This module has multiple communication interfaces, including Modbus protocol and MB+interface, which can communicate with other Modbus compatible devices and MB+network devices.

2、 Main features

Communication interface: Supports Modbus protocol and MB+interface, ensuring seamless integration with multiple devices.

Input/Output Function: With multiple digital input and output channels, it is used to connect and control sensors, actuators, and other equipment on the production line.

Accurate control: The output channel can precisely control external actuators or equipment, achieving precise control of industrial processes.

Scalability: Supports extended modules, which can be expanded according to requirements.

Data collection and monitoring: capable of collecting environmental data, equipment status, and production data, and transmitting them to the upper system for analysis and monitoring.

3、 Technical parameters

Control principle: Other (specific depending on application scenario)

Range: 100-240 (specific parameters depend on actual application scenarios)

Accuracy: 1.0-1.6 (specific parameters depend on actual application scenarios)

Specification size: 20021050mm (specific size may vary slightly depending on product version)

Operating environment temperature: 5-40 ℃

Power supply: AC 220V ± 10% 50Hz ± 5%

Power: 60VA

4、 Application scenarios

Factory automation: can be used to connect and control sensors, actuators, and other equipment on production lines, achieving automated control.

Process control: In industries such as chemical, petroleum, and energy, it can be used to monitor and control various process parameters, such as liquid level, concentration, pressure, etc.

Mechanical control: can be used to connect and control mechanical equipment, such as motors, valves, conveyor belts, etc., to achieve precise control and operation monitoring.

5、 Installation and Maintenance

Installation: Please follow the instructions in the product manual to install and ensure that the module is properly connected and secured.

Maintenance: Regularly check the connection status and working condition of the module, and promptly handle any abnormalities.

6、 Precautions

Do not use this module under ambient temperature and humidity conditions that exceed the product specifications.

During installation and maintenance, please ensure that the power is turned off to avoid the risk of electric shock.

If there is a malfunction, please disconnect the power first, and then follow the instructions in the product manual for troubleshooting.

Product image
