HITACHI LYD105A Digital Output Module

HITACHI LYD105A Digital Output Module

Product Details Introduction

HITACHI LYD105A Digital Output Module Manual

1、 Product Overview

Brand: HITACHI (Hitachi)

Model: LYD105A

Type: Digital output module

Usage: Industrial automation and CNC systems, used for output control of digital signals

2、 Main features

Output capability:

Support multiple electric heating power outputs, such as 3.6KW/16A to 6KW/30A, to meet the needs of different application scenarios.

Real time display of load current values at each heating control point, facilitating user monitoring and adjustment.

Control accuracy:

Equipped with pre tuned PID control to ensure high precision and stability of temperature control.

Choose PWM phase angle heating output to avoid controlling all power on or off, thereby reducing temperature fluctuations.

Operation and Display:

Double row LED digital display, with fault display function and alarm function, convenient for users to quickly identify and handle problems.

Multiple thermocouple (J-type/K-type/E-type) selection functions to meet the needs of different equipment and systems.

Safety performance:

Safe soft start mode to prevent excessive instantaneous starting current from burning out the heating element.

Select a specialized HHG warm runner temperature controller and pressure regulator according to the world DIN standard for easy maintenance and replacement.

3、 Technical specifications

Range: 110-221

Accuracy: ± 0.5 ℃ (displayed as ± 1 ℃)

Specification and size: 2002051mm

Electric heating power: 3.6KW/16A to 6KW/30A

4、 Installation and Maintenance

Installation: Please follow the instructions in the product manual to install and ensure that the module is properly connected and secured.

Maintenance: Regularly check the connection status and working condition of the module. If there are any abnormalities or malfunctions, please repair or replace them in a timely manner.

5、 Precautions

Do not use this module under ambient temperature and humidity conditions that exceed the product specifications.

During installation and debugging, please ensure that the power is turned off and follow the relevant safety operating procedures.

6、 Application field

The HITACHI LYD105A digital output module is widely used in industrial automation systems that require precise temperature control and electric heating power output, such as hot runner control, temperature regulation, and other scenarios.

Product image
