YOKOGAWA CP451-10 CPU module

YOKOGAWA CP451-10 CPU module

Product Details Introduction

YOKOGAWA CP451-10 CPU Module Manual

1、 Product Overview

YOKOGAWA CP451-10 is a high-performance CPU processor module designed specifically for industrial automation control systems. It greatly simplifies engineering and maintenance work by unifying process equipment control into a control diagram. The CP451-10 CPU module not only monitors the entire factory or each process, but can also be specified as a control diagram, without the need to separately specify process units or functions between different devices.

2、 Main features

Unified Control Diagram: The CP451-10 CPU module combines functional blocks and input/output into a compact control diagram, making data flow definition, control block implementation sequence, and the mixing of adjustment control and sequential control more intuitive and convenient.

Flexible connection methods: CP451-10 supports three connection methods, including dedicated signal cable connection, pressure clamp terminal connection, and MIL cable connection, to adapt to different on-site environments and equipment requirements.

Redundant configuration: The I/O module supports dual redundant configuration, which improves the reliability and stability of the system.

Debugging and diagnostic functions: The CP451-10 CPU module provides rich debugging and diagnostic functions to help users quickly identify and solve potential problems.

3、 Technical specifications

Model: CP451-10

Connection method: dedicated signal cable connection, pressure clamp terminal connection, MIL cable connection

Redundant configuration: Supports dual redundant configuration of I/O modules

Communication interface: not explicitly mentioned, but may include commonly used industrial automation communication protocols

4、 Functional characteristics

Control chart features:

Connect I/O and control blocks, visualize data flow definitions.

Define the order of control block implementation and determine the execution priority of functional blocks.

Allow for a combination of adjustable control and sequential control to achieve flexible control function configuration.

Support free signal flow between different control diagrams, enabling communication and collaboration across control diagrams.

I/O module connection:

Dedicated signal cable connections use terminal boards or relay boards to connect field devices, and prevent incorrect types of I/O modules from being inserted through signal cable interface adapters.

The pressure clamp terminal connection allows on-site devices to be directly connected to the I/O module, supporting both single configuration and dual redundant configuration types.

MIL cable connection supports customers to directly connect MIL cables to I/O modules without the need for additional wiring terminals.

5、 Installation and Maintenance

Installation: Please follow the instructions in the product manual to install and ensure that the module is properly connected and secured.

Maintenance: Regularly check the connection status and working condition of the module. If there are any abnormalities or malfunctions, please repair or replace them in a timely manner.

6、 Precautions

Please ensure that the power is turned off and follow the relevant safety operating procedures during installation and debugging.

Do not use this module under ambient temperature and humidity conditions that exceed the product specifications.

Product image

Related products:

KOLLMORGEN 6SM57M-3.000 servo

HONEYWELL 05704-A-0146 Digital

PROSOFT MVI46-MCM communicatio
