Product Details Introduction

PM866K01 3BSE050198R1 Controller Module Manual

1、 Product Overview

PM866K01 3BSE050198R1 is a high-performance interface communication controller module produced by ABB (Yaskawa), widely used in industrial automation control systems. This module provides reliable solutions for various industrial automation applications with its excellent performance and rich functionality.

2、 Main features

Communication function:

The PM866K01 module has strong communication capabilities and can communicate with other devices or systems, such as remote input/output modules, sensors, actuators, etc.

Supports multiple communication protocols, such as Ethernet/IP, Modbus TCP/IP, Profinet, etc., to meet the data exchange and communication needs of different types of devices.

Programmability:

The module has programmable functions, allowing users to configure control logic, data processing, and communication protocols through programming.

Support parameter configuration and flexible design to meet the needs of different application scenarios.

High performance:

Equipped with high-performance processors and large capacity memory, ensuring fast data processing and response speed.

The sampling rate is as high as 500kHz, and data transmission is fast and efficient.

Scalability:

The module supports modular design, and users can expand input/output channels or other functional modules as needed.

Equipped with a high-speed USB 2.0 interface, providing a variety of I/O interface options, including 16 high current digital I/O cables and a 16 bit counter/timer.

Stability and reliability:

The design is stable and reliable, using a reinforced industrial housing design, with dimensions of 4 inches x 4 inches x 1.25 inches, suitable for various harsh industrial environments.

Provide precise calibration functions, including automatic calibration and real-time hardware calibration, to ensure the accuracy of data.

Multifunctional support:

Supports multitasking and can execute multiple control tasks and algorithms simultaneously.

Equipped with functions such as data storage, remote access, and fault detection, it improves the reliability and security of the system.

3、 Technical parameters

Brand: ABB (Yaskawa)

Model: PM866K01 3BSE050198R1

Communication protocols: Ethernet/IP, Modbus TCP/IP, Profinet, etc

Sampling rate: up to 500kHz

I/O interface: 16 high current digital I/O lines, one 16 bit counter/timer

Shell Design: Reinforced Industrial Housing, Size 4 inches x 4 inches x 1.25 inches

Applicable environment: Suitable for various harsh industrial environments

4、 Application field

The PM866K01 3BSE050198R1 controller module is suitable for various industrial automation control systems, such as production line control, mechanical processing, logistics control, etc. It is also suitable for industries such as gas, water supply, sewage treatment, metallurgy, steel manufacturing, hydropower, thermal power generation, papermaking, and glass manufacturing.

5、 Installation and Maintenance

Installation: Please follow the instructions in the product manual to install and ensure that the module is properly connected and secured.

Maintenance: Regularly check the connection status and working condition of the module. If there are any abnormalities or malfunctions, please repair or replace them in a timely manner.

6、 Precautions

Please ensure that the power is turned off and follow the relevant safety operating procedures during installation and debugging.

Do not use this module under ambient temperature and humidity conditions that exceed the product specifications.

Product image
