IS220PTURH1B Analog Expansion Module

IS220PTURH1B Analog Expansion Module

Product Details Introduction

IS220PTURH1B Analog Expansion Module Manual

1、 Product Overview

IS220PTURH1B is an analog expansion module produced by GE General Electric, mainly used in industrial automation control systems. This module converts analog signals into digital signals, supports 6 analog input channels, has a 16 bit resolution, and a 100kHz sampling rate. At the same time, it has programmable gain and offset, as well as isolated input characteristics.

2、 Main features

High performance:

16 bit resolution ensures high-precision signal conversion.

100kHz sampling rate, fast response to system changes.

Programmable gain and offset, suitable for different signal ranges.

Isolate input to reduce signal interference.

Multifunctionality:

6 analog input channels to meet the needs of multiple signal sources.

Supports multiple types of analog signals, such as voltage, current, etc.

Easy to integrate:

Compatible with other industrial automation products of GE General Electric, facilitating system integration.

Standard interface, easy to connect to other devices and systems.

3、 Technical specifications

Model: IS220PTURH1B

Resolution: 16 bits

Sampling rate: 100kHz

Input channels: 6 analog input channels

Gain and offset: programmable

Input type: isolated input

4、 Installation and Connection

Installation: Please follow the instructions in the product manual for installation to ensure that the module is properly secured and away from devices and environments that may cause interference.

Connection: Use recommended connection wires and interfaces to ensure the stability and reliability of signal transmission. Follow the bus installation guide and correctly connect serial 1, serial 2, and shielded wires.

5、 Precautions

Please ensure to follow the relevant safety operating procedures during installation and connection, and ensure that the power is turned off.

Do not use this module under ambient temperature and humidity conditions that exceed the product specifications.

If you encounter any problems or questions, please contact the supplier or technical support personnel in a timely manner.

6、 Maintenance and upkeep

Regularly check the connection status and operation of the module to ensure its normal operation.

Keep the module and its surrounding environment clean to avoid damage from dust and moisture.

If any faults or abnormalities are found in the module, please contact professional personnel for repair or replacement in a timely manner.

7、 Application field

The IS220PTURH1B analog expansion module is suitable for various industrial automation control systems, including industrial control, data acquisition, testing and measurement, and other fields. Its high performance and versatility make it an important component in the field of industrial automation.

Product image
