The DS200KLDBG1ABC output module circuit board is a product of General Electric (GE), mainly used in Mark V Speedtronic systems. The following is a summary of the instruction manual for the DS200KLDBG1ABC output module circuit board, compiled based on reference articles:

1、 Product Overview

Product model: DS200KLDBG1ABC

Manufacturer: General Electric (GE)

Product type: buttons/indicator lights/display boards

Series: Mark V

DS200KLDBG1ABC is a GE component used in the Mark V Speedtronic system, designed with built-in diagnostic and online maintenance functions. It is a flexible microprocessor based control system that adopts TMR architecture to ensure system reliability and stability.

2、 Technical specifications

Main components:

32 vertical light components, 8 in each row, for a total of four rows.

Integrated circuits and resistor network arrays.

On site programmable gate array and at least one oscillation chip.

Display screen:

The top is composed of seven LED display screens, designed specifically for digital display, using 16 digits.

Connectors and components:

Multiple board connectors, including two vertical pin components.

Two jumper switches, capacitors, diodes, and resistors.

Code identification:

The circuit board is labeled with codes such as C-ESS and 6BA01.

3、 Product Description

DS200KLDBG1ABC is a large rectangular plate with well spaced components, making it easy to identify and maintain. The corners and edges of the circuit board are drilled for easy installation. This display board is mainly used to display information and is an important component of the Mark V Speedtronic system.

4、 Application field

The DS200KLDBG1ABC output module circuit board is mainly used in the control system of gas or steam turbines, and is a part of the Mark V Speedtronic system to ensure stable and reliable operation of the system.

5、 Installation and Maintenance

Installation:

Please follow the installation instructions in the product manual to ensure that the circuit board is properly connected and configured.

Maintenance:

Regularly inspect the connectors and components on the circuit board to ensure they are in good condition.

If any problems or malfunctions are found, please immediately contact the technical support department or professional maintenance personnel for handling.

6、 Precautions

Unauthorized modifications or disassembly of circuit boards are prohibited to avoid affecting their performance and safety.

During use, please ensure that the circuit board is in a dry and dust-free environment to avoid damage caused by moisture and pollution.

Product image
