BENTLEY 125720-01 Relay Module

BENTLEY 125720-01 Relay Module

Product Details Introduction

BENTLEY 125720-01 Relay Module Manual

1、 Product Overview

BENTLEY 125720-01 is a high-performance 4-channel relay I/O module designed specifically for electrical isolation and signal conversion in electrical control systems. This module has four independent relay output channels, each of which can be programmed independently to meet different application requirements. In addition, the module also includes alarm driving logic, which can drive complex logic through alarm inputs from any monitoring channel or any combination of monitoring channels in the rack.

2、 Main features

Four channel design: Provides four independent relay output channels, supporting simultaneous control of multiple devices.

Independent programming ability: Each output channel can be programmed independently to meet different application requirements.

Alarm driven logic: includes alarm driven logic, supports AND and OR logic, and can drive complex logic based on different alarm inputs.

High reliability: Ensure reliable transmission and operation of signals, suitable for long-term operation in various industrial environments and harsh conditions.

Input and output isolation: Equipped with electrical isolation function to avoid signal interference and mutual influence.

Fast response time: Meet the requirements of real-time control, ensuring the timeliness and accuracy of system response.

Multiple communication interfaces: may include digital, analog, Ethernet, USB, serial, etc., to facilitate data exchange with other devices or control systems.

Protection function: It has safety functions such as overload protection and overvoltage protection to ensure the safe operation of equipment and systems.

Easy to install and maintain: The design is simple, easy to install and maintain, reducing usage and maintenance costs.

3、 Technical specifications

Number of channels: 4 channels

Output type: Relay output

Power requirement: 24V

Weight: 2KG

Working temperature range: Depending on specific application environment

Product series: Belonging to BENTLEY's relay I/O module series

4、 Application field

The BENTLEY 125720-01 relay module is widely used in industries such as chemical, power, steel, metallurgy, and automation systems that require precise control and monitoring. It can exchange data with other devices or control systems, achieve remote monitoring and control, and improve production efficiency and safety.

5、 Installation and Maintenance

Please follow the instructions in the product manual during installation to ensure that the modules are properly connected and configured. Regularly check the operation status of the module during maintenance. If there are any abnormalities, please contact the technical support department or professional maintenance personnel in a timely manner for handling.

6、 Precautions

During use, please follow the safety regulations and operating procedures in the product manual to ensure the safety of personnel and equipment.

Unauthorized modifications or disassembly of modules are prohibited to avoid affecting their performance and security.

Product image
