ICS TRIPLEX 9300*9832*9802 base module

Elsag Bailey Process Automation is ready to help in the use and repair of its products. Contact the nearest sales office to make requests for sales, applications, installation, repair, overhaul and maintenance contract services. REPLACEMENT PARTS AND ORDERING INFORMATION When making repairs at your facility, order replacement parts from a Elsag Bailey Process Automation sales office. Provide the following information. 1. Part description, part number and quantity. 2. Model and serial number (if applicable). 3. Elsag Bailey instruction number and page number of part reference. TRAINING Elsag Bailey Process Automation has a modern training facility available for training your personnel. On-site training is also available. Contact a Elsag Bailey sales office for specific information and scheduling.

MODULE REPAIR/REPLACEMENT

 If the DSO is faulty, replace it with a new one. DO NOT try to repair the module; replacing components may affect the module performance. You can remove the module while system power is supplied. To replace a module. 1. Push and turn the two front panel captive retaining screws one-half turn to unlatch the module. It is unlatched when the slots on the screws are vertical and the open end of the slots face away from the module. 2. Gently slide the module out of the MMU. 3. Configure the replacement module switch settings. Ensure they are set the same as the original module. 4. In the same slot assignment as the original module, align the replacement module with the guide rails in the MMU; gently slide it in until the front panel is flush with the top and bottom of the MMU frame.

TECHNICAL DOCUMENTATION

 Additional copies of this instruction, or other Elsag Bailey Process Automation instructions, can be obtained from the nearest Elsag Bailey sales office at a reasonable charge.The IMDSO14 digital output module can use a NTDI01 termination unit for termination. Dipshunts on the NTDI01 unit configure the digital outputs that are sent to the process. The digital output module (DSO) outputs switch voltages of 24 VDC at 250 milliamps or 48 VDC at 125 milliamps. Figure A-1 shows the NTDI01 dipshunt without strapping, and the digital signal path from the DSO module to the field device for a termination unit application. Refer to Table A-1 to determine the dipshunt strapping to configure your application. Figure A-2 shows the terminal assignments for the digital output signals. Refer to this figure when connecting field wiring to the NTDI01. Refer to the NTDI01 instruction manual (Table 1-2) for complete termination unit information.
