Product Details Introduction

GE 369-HI-R-M-0-0-E is a comprehensive relay protector produced by General Electric (GE), commonly used for protection and monitoring in power systems. The following is the basic information about this type of relay protector:

Basic parameters

Model: 369-HI-R-M-0-0-0-E

Brand: General Electric (GE)

Type: Comprehensive relay protector

Application: Used for protection, monitoring, and control in power systems.

main features

Protection function: Provides various protection functions, including overcurrent protection, overload protection, short circuit protection, ground fault protection, etc., to protect power equipment and systems.

Monitoring function: It can monitor the operating status and parameters of the power system in real time, such as current, voltage, frequency, etc.

Communication interface: It may support various industrial communication protocols, such as Modbus, IEC 61850, etc., for data exchange and remote monitoring with upper level monitoring systems.

Operation interface: It may be equipped with an intuitive operation interface or configured and monitored through software.

Technical characteristics

Digitization: The design adopts advanced digital technology, which has the characteristics of high precision and fast response.

Programmability: It may support customized protection and control logic to adapt to different power system requirements.

Security: Integrate multiple security protection functions to ensure the safety of equipment and operators.

Application scenarios

Power system protection: widely used in power plants, substations and other power systems to protect power generation equipment, transformers, cables, etc.

Distribution system: used to protect and control distribution equipment and circuits, prevent and reduce faults and damage to the power system.

Industrial automation: In industrial automation control systems, it is used for the protection and control of power equipment.

Installation and Maintenance

Installation: According to the equipment installation guide and electrical connection diagram, install it correctly at critical locations in the power system.

Configuration: Use the configuration tools or software provided by the manufacturer to correctly configure and calibrate the parameters of the relay protector.

Maintenance: Regularly check the operation status and communication connection of the protector, promptly handle faults and abnormalities, and ensure the normal operation of the system.

Usage suggestions

Selection: Select a suitable 369-HI-R-M-0-0-E relay protector based on specific power system requirements, protection functions, and communication interface requirements.

Training: Operators and maintenance personnel should receive relevant training to understand the functions and operating procedures of the protector, and improve the efficiency and safety of system operation.

Product image
