RadiSys RB945G device motherboard

RadiSys RB945G device motherboard

Product Details Introduction

RadiSys RB945G is an industrial grade device motherboard commonly used in embedded systems and industrial applications, providing reliable performance and rich interface options. The following is detailed information and technical specifications about the motherboard:

Basic specifications

Model: RadiSys RB945G

Type: Industrial equipment motherboard

Hardware specifications

Chipset: Intel 945G chipset

Processor support: Supports Intel processors such as Pentium 4, Celeron D, etc

Memory: Supports DDR2 memory modules, with a maximum supported capacity of 4GB

Storage interface: Provides SATA and IDE interfaces for connecting hard drives and optical drives

I/O interface: Multiple input and output interfaces, including USB, serial port (RS-232), parallel port (LPT), Ethernet interface, etc

Expansion slots: including PCI and PCIe slots, supporting additional expansion cards

Display interface: Integrated with Intel GMA 950 graphics processor, supporting VGA output

Function and Features

Industrial grade design: suitable for harsh environments, with high reliability and stability

Scalability: Multiple expansion slots and rich interfaces make it easy to connect various peripherals and expansion cards

Compatibility: Compatible with multiple operating systems and embedded software, supporting diverse applications

Display support: Integrated graphics processor, supporting basic display requirements

Application scenarios

Industrial automation: used in PLC and SCADA systems to achieve factory automation control and monitoring

Embedded systems: applied to embedded applications such as medical equipment, communication equipment, traffic control systems, etc

Data collection: used for sensor networks and data collection systems, providing efficient data processing capabilities

Network security: As a core component of network security devices such as firewalls and intrusion detection

Advantages and characteristics

High performance: Supports high-performance processors and memory to meet complex industrial application requirements

Flexibility: Provides rich interfaces and extension options, facilitating system integration and functional expansion

Reliability: Industrial grade design with long-term continuous operation capability, suitable for 24/7 working environments

Easy to maintain: Modular design, easy to maintain and upgrade, reducing downtime

Maintenance and precautions

Environmental monitoring: Ensure operation under appropriate temperature and humidity conditions to avoid extreme environmental impacts on equipment performance

Regular maintenance: Regularly check the status of the power supply, cooling system, and connectors to ensure the normal operation of the system

Firmware updates: Regularly update BIOS and drivers to ensure that the system runs at its optimal state and obtains the latest features and security

Anti static measures: Take anti-static measures during installation and maintenance to protect the motherboard and electronic components from static damage

Product image
