RadiSys 61-0654-22 Composite Video Module

RadiSys 61-0654-22 Composite Video Module

Product Details Introduction

The RadiSys 61-0654-22 composite video module is a video processing module designed specifically for industrial and medical applications, capable of processing composite video signals. The following is the basic information and main features of this module:

Basic information

Manufacturer: RadiSys

Model: 61-0654-22

Type: Composite video module

Function and features

Video signal processing: This module is capable of processing composite video signals, suitable for video acquisition, processing, and output applications.

High compatibility: Supports multiple video formats and standards, with strong compatibility, suitable for different video devices.

Real time processing: Provides high-performance video processing capabilities that enable real-time video processing and transmission.

Multi interface support: equipped with multiple video input and output interfaces, making it easy to connect with other video devices.

High reliability: Designed to meet the high reliability requirements of industrial and medical equipment, suitable for use in harsh environments.

technical parameter

Video input: Supports composite video input (such as NTSC/PAL standard).

Video output: Provides composite video output, specific interface types need to refer to the product manual.

Resolution: Supports standard video resolution (such as 480i/576i, etc.), specific parameters need to be consulted in the product manual.

Power requirements: For specific power requirements, please refer to the product manual, usually DC power supply.

Working temperature: usually 0 ° C to 60 ° C, suitable for industrial and medical environments.

Size: The module size needs to refer to the product manual and is suitable for embedding into various devices.

Application scenarios

Medical equipment: Used in medical imaging equipment, endoscopes, microscopes, and other devices that require video capture and processing.

Industrial automation: applied to scenarios that require video monitoring and analysis, such as industrial monitoring and machine vision systems.

Security monitoring: Suitable for security monitoring systems, providing high-quality video capture and processing capabilities.

Broadcasting and Television: Used for video processing of broadcasting and television equipment, supporting the conversion and processing of various video formats.

Precautions for use

Installation and Maintenance: Ensure installation and maintenance are carried out in an anti-static environment to avoid damaging module components.

Heat dissipation management: Design a well-designed heat dissipation plan to ensure stable operation of the module under high load conditions.

Electrical connection: Follow the instructions in the product manual for electrical connection to ensure correct and safe connection.

Environmental conditions: Avoid using in environments that are too humid, extreme temperatures, or strong electromagnetic interference to ensure the service life and stability of the module.

Product image
