RADISYS 61-0539-10 power module
Product Details Introduction
RADISYS PBA.PFS-114-01 Control Board Card is a control board used in embedded systems. The following is general information and main features about this product:
Basic information
Manufacturer: RADISYS
Model: PBA PFS-114-01
Type: Control motherboard card
Main features and functions
Processor: Typically equipped with high-performance processors, it is used to handle complex control and data processing tasks.
Chipset: Integrated with chipsets suitable for specific application scenarios, providing good performance and power consumption ratio.
Memory: Supports DDR3 or DDR4 memory, typically with multiple memory slots, supporting maximum capacity memory expansion.
Graphics Processing: Integrated Graphics Processing Unit (GPU), supporting multimedia and graphics processing needs.
Interface: Provides a variety of external interfaces, such as USB ports, Ethernet interfaces, serial ports, audio interfaces, etc., making it easy to connect various external devices and sensors.
Scalability: Supports PCI Express slots, Mini PCIe slots, etc., allowing the addition of additional functional modules and cards to meet the specific needs of different applications.
Industrial grade design: The design meets industrial standards and has characteristics such as high temperature resistance, vibration resistance, and dust prevention, suitable for harsh industrial environments.
technical parameter
Processor support: The specific model and brand depend on the product configuration, usually supporting Intel or other mainstream processor brands.
Memory support: Supports DDR3 or DDR4 SDRAM, with specific capacity and speed depending on actual configuration.
Storage: Provides SATA interface and solid-state drive (SSD) interface for system and application storage.
Graphics support: Integrated graphics processing unit, supporting high-definition video and graphics processing.
Network: Integrated with a Gigabit Ethernet controller, providing stable network connectivity.
Power requirements: Usually DC power supply, specific power requirements depend on configuration and application scenarios.
Application scenarios
Industrial automation: used for controlling and monitoring automated production lines, executing complex process flows and data processing tasks.
Medical equipment: As the control core of medical imaging equipment and laboratory analysis equipment, it supports high-precision data processing and rapid response.
Communication equipment: Used as a controller for network devices, handling data traffic, routing, and security management.
Embedded system: Used for various embedded systems, such as traffic control systems, security monitoring systems, etc., providing stable and reliable control and data processing capabilities.
Precautions for use
Heat dissipation management: Design a well-designed heat dissipation plan to ensure system stability and longevity during high load operations.
Environmental adaptability: Follow the operating temperature range and environmental conditions in the product manual to ensure that the controller operates under normal operating conditions.
Software compatibility: Ensure the selection and configuration of appropriate operating systems and application software to fully utilize the functionality and performance of the controller.
Product image
