HONEYWELL 05704-A-0121 Output logic module

The bus cables are mounted using drop cables with BNC T-adapters that are inserted into BNC bus connectors on the CI626/CI630 communication interfaces (as shown in Figure 11 and Figure 12). This method of connection enables the exchange of a faulty CI626/CI630 communication interface without interrupting the communication in the network.The Advant Controller 110 is connected to the Advant Fieldbus 100 through a CI627 communication interface. Advant Controller 160 is connected to Advant Fieldbus 100 through a CI627 or CI631 communication interface The bus cables are mounted using Twisted Pair connectors, which are inserted into bus connectors on the CI627/CI631 communication interfaces (as shown in Figure 13 and Figure 14). This method of connection enables the exchange of a faulty CI627/CI631 communication interface without interrupting the communication in the network. Figure 14. Advant Controller 110/160 Twisted Pair Interface with Redundant Media Redundant cables are used to increase the availability; it does not enhance the communication bandwidth.

CI5201 Communication Interface

Advant Controller 400 Series controllers are connected to the Advant Fieldbus 100 using the communication interface CI520, which is mounted in a submodule carrier module in Advant Controller 450 and in the CPU in an Advant Controller 410. CI520 must always have an external modem, either a TC625 (for coaxial media) or a TC512/TC516 (for twisted pair). The cables that are used between CI520 and the external modem are TK515 (AC 450/AC460) or TK593 (AC 410)

CI5222 Communication Interface

 Advant Controller 400 Series is connected to Advant Fieldbus 100 using the communication interface CI522, which is mounted in a submodule carrier. The CI522 can be configured as single or redundant, where two CI522s can form a redundant pair.Communication interface redundancy is achieved by using two CI522s connected to a media redundant bus. CI522 Communication interface redundancy is available for Advant Controller 400 Series. CI522 is mounted in a submodule carrier module in Advant Controller 400 Series. CI522 must always have external modems – TC516 (for twisted pair), TC625 (4 items) or TC512 (4 items). The cables that are used between CI522 and the external modems are TK803V018 (AC 450/AC 460) or TK803V036 (AC 410)
