DEIF PCM4.4 ship controller

A MasterPiece 90 may be connected to the Advant Fieldbus 100 through a CI625 module. MasterBus 90 and Advant Fieldbus 100 are slave compatible. The CI625 must not be a bus administrator on the Advant Fieldbus 100. The bus administrator functionality is disabled by resetting the MASTER terminal on the CI625 DB element in the MasterPiece 90. It is not supported to use Advant Fieldbus 100 equipment on the MasterBus 90. If a MasterBus 90 is to be extended with Advant Fieldbus 100 equipment, it has to be converted to Advant Fieldbus 100. DataSet Peripherals can not be configured on the CI625 but it is possible to configure up to 100 DataSets on the module. DataSets can also be configured to the CI626 in an Advant Controller 110, but not on the CI520/CI522 in an Advant Controller 400 Series or the on CI525/CI526/CI527 in the AdvaSoft for Windows and AC 100 OPC Server.

Redundant line error detection

is not used in the slave functionality on the CI625. Therefore, an Advant Fieldbus 100 that uses CI625s must have one AF 100 communication interface placed at each end of the bus for full redundant line error detection.This section is related to configuration of Advant OCS with Master Software (Advant Controller 410 and Advant Controller 450). For information on how to configure the Advant Fieldbus 100 for Advant OCS with MOD 300 Software, refer to the Advant Controller 460 User’s Guide. Table 12 and Table 16 are related to Advant OCS with MOD 300 Software. A station is connected to the Advant Fieldbus 100 through a communication interface. There are different communication interfaces for each type of station. The communication interface performs several functions in the network, such as managing process data and message transfer, the bus master function, and the configuration of cyclic data packages (CDPs). The communication interface is configured from the station. The station provides attributes to install the communication interface, make it operational and supervise its performance. This procedure is described in detail in Section 5, Maintenance and Fault

CDP time out mechanism

For earlier versions of the communication interfaces, the CDP valid flag is reset after five cycles. For monitoring CDP data, a time out mechanism is used. CDPs are sent cyclically on the bus. For each CDP, a valid flag is set each time the CDP is received. If the CDP is not received during the last four cycles, the valid flag is reset. Tracing.

The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, machinery, electronics, automobile manufacturing, tobacco, plastics machinery, electric power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution and so on
