Yaskawa CACR-IR30SFB servo driver

Yaskawa CACR-IR30SFB servo driver

Product Details Introduction

The Yaskawa CACR-IR30SFB servo driver, as a product under the Yaskawa brand, can be summarized and summarized from multiple aspects. The following is a detailed analysis of the characteristics of the product:

1. High precision control

Three loop control algorithm: Yaskawa CACR-IR30SFB servo drives generally use vector control based current, speed, and position three loop control algorithms. This algorithm can ensure high-precision positioning of the servo system and meet the requirements of high-precision transmission systems.

Positioning accuracy: Through precise position, speed, and torque control, high-precision transmission system positioning is achieved, meeting the strict accuracy requirements of industrial robots, CNC machining centers, and other automation equipment.

2. Powerful performance

Wide speed regulation range: The servo drive has a wide speed regulation range, and the motor can operate smoothly from the lowest speed to the highest speed. The torque fluctuation is small, especially at low speeds, it can still maintain a stable speed without any crawling phenomenon.

Strong overload capacity: The motor has a large and long-term overload capacity to meet the requirements of low speed and high torque. Generally, DC servo motors require an overload of 4-6 times within a few minutes without damage.

Fast response: In order to meet the requirements of fast response, the motor design has a small moment of inertia and a large locked rotor torque, as well as a time constant and starting voltage as small as possible.

3. Intelligence and Networking

Digital Signal Processor (DSP): Using DSP as the control core, it can achieve complex control algorithms, digitization, networking, and intelligent control.

Software program: The software program of the servo drive includes the main program, interrupt service program, data exchange program, etc., supporting communication with the upper computer, facilitating system integration and remote monitoring.

4. Reliability and stability

Fault detection and protection: Equipped with built-in fault detection and protection circuits for overvoltage, overcurrent, overheating, undervoltage, etc., ensuring that the driver can quickly cut off power in case of abnormal situations, protecting the motor and driver from damage.

Soft start circuit: Add a soft start circuit to the main circuit to reduce the impact of the start process on the driver, and improve the stability and reliability of the system.

5. Environmental adaptability

Environmental adaptability: Servo drives have strong adaptability to temperature, humidity, vibration and other environments, and can operate stably in harsh industrial environments.

6. Widely applicable

Application field: Yaskawa CACR-IR30SFB servo drives are widely used in high-end automation equipment such as industrial robots, CNC machining centers, and automated production lines, and are an important component of modern motion control.

In summary, the Yaskawa CACR-IR30SFB servo driver occupies an important position in the field of industrial automation due to its high precision control, powerful performance, intelligence and networking, high reliability, and wide application areas.

Product image
