Product Details Introduction

Yaskawa CACR-SR44BC1CSY349 is a high-performance servo driver widely used in the field of industrial automation. This driver has advanced control algorithms and rich functions, which can accurately control the speed and position of servo motors and is suitable for various complex motion control tasks.

Main features:

High precision control: adopting advanced vector control and servo control technology to achieve high-precision position, speed, and torque control.

Multifunctional: Supports multiple control modes such as position control, speed control, and torque control, suitable for various application scenarios.

Easy to integrate: compact design, easy to integrate with various industrial automation equipment and systems.

Powerful protection function: equipped with multiple protection functions such as overcurrent, overvoltage, undervoltage, overheating, short circuit, etc., to ensure the safe operation of the equipment.

Flexible communication capability: Supports multiple industrial communication protocols for remote monitoring and control.

Technical specifications:

Input voltage: three-phase AC 200-230V

Output power: 44kW

Output current: maximum 200A

Control methods: vector control, V/f control

Maximum output frequency: 400Hz

Communication interface: RS-232/RS-485, optional modules such as Profibus, DeviceNet, EtherNet/IP, etc

Application field:

Industrial automation: suitable for high-precision equipment such as CNC machine tools, injection molding machines, textile machinery, etc.

Robots: widely used in motion control of industrial robots and automated production lines.

Printing and packaging: used for precise motion control of printing machines and packaging equipment.

Material processing: achieving precise speed and position control in equipment such as conveyor belts and cranes.

Semiconductor manufacturing: used for high-precision positioning control in semiconductor equipment.

Installation and maintenance:

Installation: It is carried out by professional technicians to ensure the correct connection between the power supply and servo motor, and to ensure proper grounding.

Debugging: Use Yaskawa's dedicated debugging software to set parameters and debug, ensuring that the device runs at its optimal state.

Maintenance: Regularly check the operation status of the drive, clean the heat sink, check the connection condition, and prevent loosening and aging.

Common problem solving:

Overcurrent fault: Check if the connection between the motor and driver is correct, and ensure that there is no short circuit or overload.

Communication failure: Check if the communication cable connection is secure, confirm if the communication parameters are set correctly, and ensure that the communication module is working properly.

Abnormal noise and vibration: Check whether the motor and mechanical load are normal, eliminate mechanical faults, and ensure smooth system operation.

Usage suggestions:

Environmental requirements: Ensure that the installation environment is clean and dry, and avoid the impact of dust and moisture on equipment operation.

Temperature control: Ensure that the operating environment temperature of the equipment is within the specified range to prevent overheating of the equipment.

Regular maintenance: Follow the requirements of the equipment manual for regular maintenance and upkeep to extend the service life of the equipment.

Product image
