Hydran M2-X Transformer Gas Monitor

GE Hydran M2-X Transformer Gas Monitor

Product Details Introduction

The GE Hydran M2-X is a device used for transformer gas monitoring, designed to provide early fault warning so that maintenance personnel can take timely measures to prevent serious faults from occurring. The following is detailed information about the GE Hydran M2-X transformer gas monitor:

main features

Multi gas monitoring: capable of monitoring various key gases in transformer oil, including hydrogen (H ₂), carbon monoxide (CO), acetylene (C ₂ H ₂), ethylene (C ₂ H ₂), methane (CH ₂), ethane (C ₂ H ₂), propane (C ₂ H ₂), etc.

Dissolved Gas Analysis (DGA): By analyzing the gas dissolved in transformer oil, abnormal conditions and fault modes inside the transformer, such as arc discharge, overheating, and partial discharge, are identified.

Real time monitoring: Provides real-time data monitoring and alarm functions, helping users intervene in the early stages of problems.

Remote access: Supports remote access and management through the network, facilitating centralized monitoring and data analysis.

Data storage and analysis: With built-in data storage function, it can record long-term monitoring data and perform trend analysis to help predict and prevent potential problems.

Easy to install and integrate: The design is simple, easy to install on transformers, and can be integrated into existing monitoring systems.

technical specifications

Monitoring gases: hydrogen (H ₂), carbon monoxide (CO), acetylene (C ₂ H ₂), ethylene (C ₂ H ₂), methane (CH ₂), ethane (C ₂ H ₂), propane (C ₂ H ₂)

Measurement principle: Gas sensor

Communication interfaces: RS485, Modbus, Ethernet, etc

Working temperature range: -40 ° C to+55 ° C

Protection level: IP66

application area

Power Transformer: Used for online monitoring of dissolved gases in power transformers to detect potential faults in advance.

Industrial transformer: applied on large transformers in industrial facilities to ensure the reliability and safety of equipment operation.

Wind farm transformer: applied in wind farm transformers to monitor the health status of wind turbines.

Monitoring the status of other key equipment, such as reactors, transformers, etc.

advantage

Improving reliability: By real-time monitoring and early fault warning, the operational reliability of transformers can be improved.

Reduce maintenance costs: promptly identify and address potential issues, reduce unplanned downtime and maintenance costs.

Extending equipment lifespan: Through effective condition monitoring and preventive maintenance, the service life of transformers can be extended.

Enhance safety: prevent the occurrence of major faults and accidents, and ensure the safe operation of the power grid and equipment.

The GE Hydran M2-X transformer gas monitor is an important tool for transformer status monitoring, helping users achieve intelligent operation and fault prevention.

Product image
