HYDRAN H201Ti fault detector

HYDRAN H201Ti fault detector

Product Details Introduction

GE Hydran H201Ti is a fault detector used for transformers and other oil immersed electrical equipment, mainly monitoring the gas dissolved in transformer oil to achieve early fault warning. The following is detailed information about the Hydran H201Ti fault detector:

main features

Single gas monitoring: Hydran H201Ti focuses on monitoring hydrogen (H ₂) in transformer oil, as hydrogen is an early indicator of many types of electrical faults, such as arc discharge and overheating.

Early fault detection: By continuously monitoring the hydrogen content, early warning is provided to help users intervene before the problem evolves into a serious fault.

Economically efficient: With simple design and low cost, it is an economical solution for monitoring faults in transformers and oil immersed electrical equipment.

Easy to install: The device design is simple and easy to install on existing transformers and electrical equipment, without the need for complex installation processes.

Local and remote monitoring: Supports local data reading and remote monitoring functions, allowing users to easily access monitoring data.

technical specifications

Monitoring gas: Hydrogen (H ₂)

Measurement range: 0-2000 ppm

Accuracy: ± 10% or ± 25 ppm (whichever is higher)

Response time: Under 90% gas concentration change, the response time is less than 30 minutes

Communication interface: 4-20mA analog output, RS485 (optional)

Working temperature range: -40 ° C to+55 ° C

Protection level: IP65

application area

Power Transformer: Online monitoring of hydrogen content in power transformers for early detection of faults.

Industrial transformer: Used for large transformers in industrial facilities to ensure the reliable operation of equipment.

Key equipment of the power system: suitable for other oil immersed electrical equipment that requires dissolved gas monitoring, such as reactors and transformers.

advantage

Improve equipment reliability: By early detection and warning, improve the operational reliability of transformers and oil immersed electrical equipment.

Reduce maintenance costs: promptly identify and address potential issues, reduce unexpected downtime and maintenance costs.

Simplified installation and maintenance: Compact equipment design, easy installation and maintenance.

Real time monitoring: Provides real-time data monitoring, making it easy for users to keep track of device status at any time.

Installation and maintenance

The design of Hydran H201Ti is simple, and the installation process includes the following steps:

Choose installation location: Choose a suitable location for the transformer or equipment oil tank for installation.

Install the sensor: Install the sensor on the wall of the oil tank to ensure it is in full contact with the transformer oil.

Connect power and communication lines: Connect the power and communication lines (if any) to ensure that the device can function properly and transmit data.

Calibration and testing: Conduct calibration and functional testing according to the manufacturer's instructions to ensure accurate and reliable operation of the equipment.

GE Hydran H201Ti is an economical, efficient, and reliable fault detection tool suitable for various electrical equipment that needs to monitor dissolved gases. By continuously monitoring the hydrogen content, users can promptly identify potential issues and take necessary preventive measures to ensure the safe operation of the equipment.

Product image
