Alstom CDG31EF004SBCH overcurrent relay

Alstom CDG31EF004SBCH overcurrent relay

Product Details Introduction

Alstom CDG31EF004SBCH overcurrent relay is a protective device designed specifically for monitoring and protecting overcurrent conditions in power systems. The following are the main characteristics and functions of the overcurrent relay:

Product features

Overcurrent protection function:

The main function is to monitor the current in the circuit. Once an overcurrent situation exceeding the preset threshold is detected, it will trigger a protective action, such as cutting off the circuit or issuing an alarm.

High precision and fast response:

Adopting high-precision sensors and fast response circuit design, ensuring timely and accurate triggering of protective measures in case of current overload.

Adjustable settings:

Support users to adjust and set the triggering threshold and action logic of overcurrent protection according to specific application needs.

Electrical isolation:

Having good electrical isolation ability to prevent interference or impact on the circuit caused by overcurrent relays themselves.

Modular design:

Modular structural design facilitates installation, maintenance, and replacement, reducing system downtime and maintenance costs.

Environmental adaptability:

The design can adapt to various industrial environmental conditions, with characteristics such as anti-interference, high temperature resistance, and moisture resistance, ensuring stable operation under harsh conditions.

Reliability and Security:

By complying with relevant international electrical and safety standards, ensure that products meet industry requirements in terms of safety and reliability.

Widely applicable:

Mainly used for distribution protection, power equipment protection, and overload protection during power transmission and distribution in power systems.

application area

Electric power substation: used to protect transformers, circuit breakers, and other equipment in the substation from the impact of overload currents.

Industrial control system: used for current protection in industrial equipment and control systems to prevent equipment damage or accidents.

Power plants and transmission networks: used for overcurrent protection in power generation equipment and power transmission systems, ensuring the stability and safety of power supply.

technical parameter

Specific technical parameters (such as rated current range, rated voltage, action time, reset time, etc.) can be referred to the product manual or contact ALSTOM's technical support team for detailed information.

summary

The Alstom CDG31EF004SBCH overcurrent relay provides important protection measures for the power system through its reliable overcurrent protection function, high precision, and fast response ability, ensuring that equipment and systems in the circuit can operate safely and reliably.

Product image
