10QT01 GJR2209300R0001 10QT01A-ER0001 module

   Green LED indicating that the CI522 is in OPERATIONAL state, i.e. executing. In case the module is configured as Bus Administrator it is now taking part in the administration of the communication on the bus.Red LED, set when the CI522 Is in FAULT state and does not take part in any communication.Yellow LED, set when the module is primary in a redundant CI522 configuration.Green LED, set in a redundant CI522 configuration when the back-up is ready to handle switch over.The communication interface CI522 is inserted into the Advant Controller 450/460 submodule carrier or in the Advant Controller 410 CPU The communication interface CI526 is used for connection of an AC 100 OPC Server based Personal Computer to the Advant Fieldbus 100. It can handle up to 3999 CDPs and have full functionality of a bus administrator, it can be a bus master on the bus. It is used for the PC based operator station application. CI526 has the capability to both send and receive the time synchronization signal.

Technical Data of Communication Interface CI526

The communication interface CI526 is mounted in an ISA slot in the Personal Computer. CI526 Interface for Advant Fieldbus 100 Hardware The Advant Fieldbus 100 Interface hardware consists of the following: • CI526 interface board The CI526 interface board fits in the IBM PC AT ISA bus and supports single or redundant bus cabling. • TC625/TC512/TC516 modems ne or two TC625 modems (single or redundant) for Coaxial cable or, alternatively, one TC630 modem for single optical cable. • RA545 mounting plate For mounting of the modems and the power supply unit • SB512 power supply unit Power supply for the TC625/TC512/TC516 modem mounted on the same mounting plate. • TK549 connection cable A cable for connection between the CI526 board and the TC625 modem(s).

TC625 modem installation

 Connect the TK549 connection cable to the CI526 interface board, the TC625 modem and the SB512 power supply unit, as shown in Figure 83.The TC625 modem is connected to the Advant Fieldbus 100 network with a BNC Tadapter. A redundant media modem/coax. cable is mounted in a similar way to the other connector on the interface unit. TC512/TC516 Modem Installation Twisted pair media is connected to the interface by the TC512/TC516 modem in a similar way as the TC625 modem.
