UAD149 3BHE014135R0011 UAD149A00-0-11 module

The IMFEC1
module can use the NTAI05 termination unit for point-to-point operation. Select the input type of each channel through the dipshunts on the termination unit. The FEC module can accept inputs of 4 to 20 milliamps, 1 to 5 VDC, 0 to 1 VDC, 0 to 5 VDC, 0 to 10 VDC and -10 to +10 VDC. NOTE: Input jumpers J6 through J20 on the IMFEC11 board must be set to the voltage position. Refer to IMFEC11 Input Jumpers (J6 through J20) in Section 3. CONFIGURING INPUTS Figure A-1 shows the input signal path through an NTAI05 dipshunt. Table A-1 shows NTAI05 dipshunt configurations. Figure A-2 shows module to termination unit cabling and Figure A-3 shows the NTAI05 terminal assignments.

The IMFEC11 module

must use the NTFB01 termination unit to terminate FSK digital smart transmitters on a field bus. All inputs must be in an FSK digital field bus mode when using the NTFB01 termination unit. There are no other input types available when operating in this mode. The IMFEC1
module can use the NIAI04 termination module for termination in point-to-point applications. Select the input type of each channel through dipswitches on the NIAI04 termination module. The FEC module can accept inputs of 4 to 20 milliamps, 1 to 5 VDC, 0 to 1 VDC, 0 to 5 VDC, 0 to 10 VDC and -10 to +10 VDC.
