HIMA Z7306 processor module

Thanks to a widespread R&D on substrates, ink chemistries, printheads and machinery, INX Digital is proud to deliver EVOLVE™ Advanced Digital Solutions for cylindrical printing. Our complete solutions includes high quality inks optimized for metal printing, a unique JetINX™ print engine, software, workflow integration and customized service. - Best in class performance - Best in class image quality - UV LED cure technology - Short-run cylindrical production - XAAR patented through-flow technology™ - Produce prototypes and proofs in minutes Printer output may vary depending on type of print data file, application, media, environmental conditions, print speed, or other variables. Many of these variables can be controlled by the operator to optimize to production and output quality requirements. Only approved consumables purchased from INX International Ink Co. or authorized distributors and designate for use in the CP800 Cylindrical Proofer are warranted for use in the CP800.

System 800xA hardware selector

The TU846 is a module termination unit(MTU) for redundant configuration of the field communication interface CI840/CI840A and redundantI/O. TheMTU is a passive unit having connections for power supply,two electricalModuleBuses,two CI840/CI840A and two rotary switches for station address (0 to 99) settings. AModuleBus Optical Port TB842 can be connected to TU846 via TB846. Four mechanical keys,two for each position, are used to configured theMTU for the righttypes of modules. Each key has six positions,which gives a total number of 36 different configurations. Module Termination Unitfor dual CI840/CI840A,redundantI/O. TU846 are usedwith redundantI/O modules and TU847 with single I/O modules. The maximumModuleBus length fromthe TU846 to the ModuleBus terminator is 2.5 meters. TU846/TU847 needs space to the leftin order to be removed. Cannot be replacedwith power applied.

Features and benefits

• Power supply connection. • Two PROFIBUS connections. • Two service tool connections. • Two rotary switch for station address setting. • Connection for twoModuleBuses. • Connector forModuleBus Optical Port. • Mechanical keying prevents insertion of thewrong module type. • Latching device to DIN rail for locking and grounding. • DIN rail mounted.
