Product Details Introduction

GE Multilin EP5NNG5HNN is a high-performance feeder protection system designed specifically for the protection and monitoring of power systems. This device provides advanced protection, monitoring, and control functions, suitable for various power applications. The following is the detailed information of the system:

Product Overview

Model: EP5NNG5HNN

Product Type: Feedline Protection System

main features

Comprehensive protection function: It integrates multiple protection functions, such as overcurrent protection, undervoltage protection, overvoltage protection, ground fault protection, etc.

Real time monitoring: Provides real-time power system status monitoring to help detect and diagnose problems in the system.

Powerful communication capability: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with other devices and systems.

User Interface: Equipped with an intuitive graphical user interface (GUI) for easy configuration, operation, and monitoring.

technical specifications

Model: EP5NNG5HNN

Protection function:

Overcurrent protection: detects and responds to overcurrent situations to protect equipment in the power system.

Undervoltage protection: prevents equipment from operating under undervoltage conditions and protects the equipment from damage.

Overvoltage protection: prevents equipment from operating under overvoltage conditions, ensuring system stability.

Ground fault protection: Detect ground faults and provide protection to reduce the impact of faults on the system.

Short circuit protection: Quickly respond to short circuit situations to prevent equipment damage.

Data Collection: Supports real-time collection and analysis of current, voltage, power, and other data.

Display and Interface: Equipped with a high-resolution display screen and user-friendly interface, providing clear data display and operational functions.

Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850, etc., to achieve data transmission and system integration.

Environmental temperature: typically suitable for a working temperature range of 0 ° C to 50 ° C.

Installation method: Supports panel installation or DIN rail installation, making it easy to integrate into existing systems.

application area

Power system protection: used to protect equipment such as feeders, transformers, generators, etc. in the power system, ensuring the safety and stability of the system.

Industrial automation: suitable for power protection and monitoring in industrial automation systems.

Building power management: used for power system protection and fault detection inside buildings.

Energy management: Provide detailed energy consumption data and protection functions to help optimize energy use.

Installation and maintenance

Installation: The device can be installed through a panel or DIN rail. Please refer to the product manual for specific instructions.

Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.

advantage

High performance protection: Provides comprehensive protection functions to ensure the safety and reliability of the power system.

Flexibility: Supports multiple protection functions and configuration options to adapt to different power system requirements.

Compatibility: Supports multiple communication protocols and has good compatibility with other devices and systems.

User friendly: Equipped with an intuitive interface and features, it simplifies the operation and configuration process.

summary

The GE Multilin EP5NNG5HNN feeder protection system is a powerful and reliable protection device suitable for the protection and monitoring of power systems. Its comprehensive protection functions, powerful communication capabilities, and user-friendly interface make it an ideal choice for power systems and industrial automation applications.

Product image
